CHANGING THE SCATTER PLOT DISPLAY OPTIONS
172
Affymetrix GeneChip ®
The Display tab of the MPAM or DM Mapping Analysis Options
dialog box allows you to control the display of the Scatter Plot:
• Call threshold
- Turn the display of the radii (MPAM) or the threshold (DM)
on and off
- Change the call zone radius (MPAM)or the call threshold (DM)
value displayed
• Display highlighted features only
• Control the display of the different allele calls:
- Color
- Style
- Size
To show the Display tab:
Click the Options button
1.
The Mapping Analysis Options dialog box opens.
Click the Display tab to view display options
2.
The other tabs of the
you to control the display in the MPAM or DM table
NetAffx™ options (see page 285).
Click Defaults to return settings to the default values.
3.
Genotyping Analysis Software User's Guide
.
Mapping Analysis Options
(Figure 5.27).
dialog box allow
and select
