- Page 1 Temperature + Humidity Operator’s Manual NEWPORT Electronics, Inc. ® http://www.newportUS.com/iServer...
- Page 2 It is the policy of NEWPORT to comply with all worldwide safety and EMC/EMI regulations that apply. NEWPORT is constantly pursuing certification of its products to the European New Approach Directives. NEWPORT will add the CE mark to every appropriate device upon certification.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Part 1: Introduction Safety and EMC Considerations................2 Before You Begin ....................2 Description ......................2 Part 2: Hardware Mounting ......................4 DIP Switches......................4 Parts of iServer Unit ...................5 Disassembly Instruction ..................6 Network Communication Interfaces ..............7 2.5.1 10Base-T RJ-45 Pinout.................7 2.5.2 10Base-T Crossover Wiring ..............7 Relay Wiring Connections .................7 Running on Battery Power ................7... - Page 4 LIST OF FIGURES: Figure 1.1 iServer and iLD Big Display the Ethernet Network ......3 Figure 2.1 Mounting ....................4 Figure 2.2 DIP Switches...................4 Figure 2.3 Parts of iServer Unit................5 Figure 2.4 Opening the Unit ..................6 Figure 2.5 RJ45 Pinout ....................7 Figure 2.6 10Base-T Crossover Cable Wiring ............7 Figure 2.7 Relay Connections ................7...
- Page 5 NOTES, WARNINGS and CAUTIONS Information that is especially important to note is identified by the following labels: • NOTE • WARNING or CAUTION • IMPORTANT • TIP NOTE: Provides you with information that is important to successfully setup and use the iServer. CAUTION: Tells you about the risk of electrical shock.
-
Page 6: Part 1: Introduction
PART 1 INTRODUCTION 1.1 Safety and EMC Considerations Refer to the CE Approvals Section. EMC Considerations • Whenever EMC is an issue, always use shielded cables. • Never run signal and power wires in the same conduit. • Use twisted-pair wires for signal connections. •... -
Page 7: Figure 1.1 Iserver And Ild Big Display The Ethernet Network
Award-winning Technology. The iServer is simple to install and use, and features award winning iServer technology that requires no special software except a Web browser. The iServer connects to an Ethernet Network with a standard RJ45 connector and sends data in standard TCP/IP packets. It is easily configured with a simple menu using a Web browser and can be password protected. -
Page 8: Part 2 Hardware
PART 2 HARDWARE 2.1 Mounting Position unit where required. Mark and drill holes as required. If unit is to be mounted on a flat 3.55 [90.2] surface, you may take the 3.05 [77.5] bottom rubber feet off the unit. 2.42 [61.6] 2.2 DIP Switches The iServer is shipped with all DIP switches in "OFF"... -
Page 9: Parts Of Iserver Unit
2.3 Parts of the iServer Unit iServer iServer Reset Button iServer LEDs RJ45 interface ACTIVITY Side or Bottom NETWORK LINK TX-TRANSMIT Wire Entry for RX-RECEIVE Relay Connector ETHERNET RESET Removable Plug 16 Digit Connector for Relays LCD Display under the Cover Probe Flash Handle... -
Page 10: Disassembly Instruction
2.4 Disassembly Instruction You may need to open the unit for one of the following reasons: • To wire relay connector. (Refer to Figure 2.7) • To connect or replace the battery. • To change S5 jumper. In the absence of AC power, and if S5 is installed, the LCD Backlight and iServer Board will be on and running on the battery power. -
Page 11: Network Communication Interfaces
2.5 Network Communication Interfaces 2.5.1 10Base-T RJ-45 Pinout Name Description The 10BASE-T Ethernet network + Transmit Data (RJ-45) system is used in the iServer - Transmit Data for network connectivity. The 10 Mbps + Receive Data twisted-pair Ethernet system operates Not Connected over two pairs of wires. -
Page 12: Part 3: Network Configuration
PART 3 NETWORK CONFIGURATION 3.1 Network Protocols The iServer can be connected to the network using standard TCP/IP protocols. It also supports ARP, HTTP (WEB server), DHCP, DNS and Telnet protocols. 3.2 Ethernet (MAC) Address MAC (Media Access Control) address is your computer's unique hardware number. When you're connected to the LAN from your computer, a correspondence table relates your IP address to your computer's physical (MAC) address. -
Page 13: Dhcp
3.3 DHCP DHCP, Dynamic Host Configuration Protocol enables individual computers or devices to extract their IP configurations from a server (DHCP server). If the DHCP is enabled on your iServer, as soon as the iServer is connected to the network, there is an exchange of information between DHCP server and the iServer. -
Page 14: Ip Address
3.5 IP Address Every active device connected to the TCP/IP network must have a unique IP address. This IP address is used to build a connection to the iServer. Every computer using TCP/IP should have a unique 32-bit address. It is divided into two portions, the network ID and the host ID. -
Page 15: Part 4: Operations
This iServer can be used and configured in several ways, depending on user’s preference and network setup. It can be configured using a Web browser, like Netscape or Internet Explorer. It can also be configured using NEWPORT’s iCONNECT Configuration Software. -
Page 16: Iconnect Software
4.1 iCONNECT Software The iServer may also be assigned an IP Address by using the iCONNECT software. Download the iCONNECT software from the website listed in this manual. Install iCONNECT software on a networked PC. This software is compatible with Windows 95, NT, 2000, and XP. -
Page 17: Setting A New Ip Address Over The Network
4.2 Setting a New IP Address over the Network Besides using the iCONNECT software, you may use the iServer’s default IP address to access it and assign a new IP address to it. The iServer is shipped with a default IP address of 128.100.101.254 and Subnet Mask of 255.255.0.0. -
Page 18: Setup And Operation Using A Web Browser
4.3 Setup and Operation Using a Web Browser • Start your web browser. • In the URL field, type http://eisxxxx using the last four-digits from the MAC address label located on the device if DHCP and DNS are used. If a static IP address is used, then simply type http://x.x.x.x, where x.x.x.x is the iServer’s IP address. -
Page 19: Reading Sensor
4.3.1 Read Sensor Read Sensor • Click on . In a few seconds the following page (Figure 4.7) will appear with all default values of 100.00. Then the actual readings of Temperature, Humidity and Dewpoint will display. • This page automatically updates the Temperature, Humidity, and Dew Point values. •... -
Page 20: Java Runtime Environment 1.5 (5.0) Setup Instructions
4.3.1.2 Java Runtime Environment 1.5 (5.0) Setup instructions 1. Go to your computer's Control Panel. Open the Java Plug-in 2. Click on "Settings" & "View Applets" in the "General" tab. 3. Select the "Settings" button on the General Tab Un-check the "Enable Caching" box. Then close dialog box to show the General Tab again 4. -
Page 21: Adjustable Chart
4.3.2 Adjustable Chart Chart • Click on , the following page (Figure 4.8) should appear. The Java™ Applet graph displays Temperature and Humidity and can be charted across the full span (0-70ºC, and 0-100% RH) or within any narrow range (such as 20-30ºC). The time-base can display one minute, one hour, one day, one week, one month or one year. -
Page 22: Retrieving Data From Flash
4.3.3 Retrieving Data from Flash To retrieve and graph the data that is stored in the Flash Memory, you have two options: OPTION 1: You can use the iServer’s WEB interface to chart the data stored in the flash memory. Click on the “Chart”... -
Page 23: Access Control
4.3.4 Access Control This section describes the "Access Control" page of the iServers’s Web interface. This page allows the users to set up the network and security parameters of the iServer. To get into the Access Control page, the user will be prompted with an Admin Password. The default Admin password is 00000000 and is changeable, if desired. -
Page 24: Configuration
4.3.5 Configuration Setting up the Flash Memory Card can be done in the Configuration/Device Setup Menu. From the Home Page click on to get to the menu (see Figure 4.11). Configuration General Description of the Configuration/Device Setup Menu: There are two general sections “Flash Card Memory”... -
Page 25: Figure 4.11 Configuration/Device Setup Menu
4.3.5 Configuration (continued) Figure 4.11 Configuration/Device Setup Menu Below are the definitions of terms used in the Configuration/Device Setup Menu. A) Device Setup Clicking on the No. 1, 2, or 3 allows you to modify the Sensor Parameters (See Section 4.3.6 for more details). -
Page 26: Figure 4.12 Sensor Parameter Menu
B) Real Time Clock RTC Date and Time: The formats are mm/dd/yyyy and hh:mm:ss. The exact formats are required otherwise an error message will appear in the Title box. Note: time is military time/24 hour based. Adjust RTC Only: If checked, the clock will be updated and nothing else, provided that “Activation”... - Page 27 F) Flash Recording Title: Editable box with up to 16 characters long. The given name will display as a title on the Chart and Read Sensor pages either for the real-time data or the stored data. Degree Unit: The unit of temperature either in degree Fahrenheit or degree Centigrade. LCD/PWR: The selections are “ON ”, “OFF ”, and “UPS”.
- Page 28 NOTE 1: While the recording is in progress, the letter “R” of RH, located on the LCD screen blinks continuously. NOTE 2: Downloading data and recording can not be done at the same time. While downloading data, the writing process to the flash memory will be internally disabled while the data is being read from the memory flash.
- Page 29 RS-232 or RS-485 interface. A computer program, such as the Mail Notifier, NEWPORT OPC Server or httpget can send requests and obtain readings through the Terminal Server using a networking protocol called TCP.
-
Page 30: Sensor Parameter
4.3.6 Sensor Parameters • In the first column of Configuration/Device Setup menu (Figure 4.11), click on No. 1 to view and modify the Sensor Parameters Menu for Temperature. Sensor Parameter http://128.100.101.254 SENSOR PARAMETERS You may Device No. 1 type any ASCII Device Name: Temperature... -
Page 31: Telnet Setup
NEWPORT software or with other programs supporting TCPIP communications. The Port 1000 access can be used with NEWPORT software and may be needed with some iServer products when you need to view readings from the web page while simultaneously... -
Page 32: Httpget Using Port 1000
4.5.1 HTTPGET using Port 1000 You can setup and read the information from the iServer by using the HTTPGET program. The following program can be used to read data from the embedded server firmware by using TCP port 1000. The command string is sent to this TCP port, then the response can be read back from the same socket. -
Page 33: Httpget And Arp To Setup Device Ip Address
4.5.2 HTTPGET and ARP to setup Device IP Address Use the iCONNECT software, which may be downloaded from our website, to do these IP changes whenever possible. Use ARP first to assign the mac address to a static IP address in computer arp table by this command: apr –s 128.100.101.254 00-03-34-00-00-06-b6 Then use the following command to assign new IP to the device:... -
Page 34: Arp Protocol
4.6 ARP Protocol ARP is the Internet layer protocol responsible for matching or obtaining the MAC (hardware) address that corresponds to a particular IP address. The ARP command allows the user to view the current contents of the ARP cache of the local computer (residing on the same network). -
Page 35: Mail Notifier Software
4.7 Mail Notifier Software The Mail Notifier Software can be used only with NEWPORT Electronics instruments. For complete information of how to use the Mail Notifier software, click on the Help menu of the main window. The Mail Notifier software generates email notifications for alarm conditions of the devices with embedded iServer board or connected via the stand alone iServer units, attached to measurement devices with RS232/485. -
Page 36: Program Options Setup And Configuration
4.7.2 Program Options Setup and Configuration Complete program setup requires: • Entering a recipient for the email • Specifying connection details to MAPI services. • Defining alarms for devices, and selecting how and when the email will be active. Figure 4.16 iServer Mail Notifier Profile Setup The “Send To”... -
Page 37: Device Setting Setup And Configuration
4.7.3 Device Setting and Configuration Device setup requires: • Entering the IP address for iServer device (for example 128.100.101.254). • Specifying Socket number (1000 or 2000 depending on iServer settings). • Defining RS485 Unit # interface address (1 to 199). Enter "0" for RS232 interface or for iServer. -
Page 38: Part 5: Specifications
Supported Protocols: PART 5 TCP/IP, UDP/IP, ARP, ICMP, DHCP, DNS, SPECIFICATIONS HTTP, and Telnet SENSOR SPECIFICATIONS LED Indicators: Network Activity, Network Relative Humidity (RH) Link, Transmit and Receive Accuracy/Range: ±2%for 10 to 90% LCD Display: 16 digits, 6mm (0.23”) ±3%for 0 to 10% and 90 to 100% Processor: Enhanced 8051, 22 MHz Hysteresis: ±1% RH Memory: 512 Kbytes Flash, 16 Kbytes SRAM... -
Page 39: Part 6: Factory Preset Values
PART 6 FACTORY PRESET VALUES PRESET PARAMETERS FACTORY DEFAULTS Network Interface: IP Address 128.100.101.254 Gateway Address 0.0.0.0 Subnet Mask 255.255.0.0 Device Host Name eis and Last 4 digits from the MAC address Login Password 12345678 Admin Password 00000000 DHCP Disabled Flow Control None End Character... -
Page 40: Appendix Aglossary
APPENDIX A GLOSSARY User of this manual should be familiar with following definitions: ARP (Address Resolution Protocol) is a protocol for mapping an Internet Protocol address (IP address) to a physical machine address that is recognized in the local network. For example, the IP address in use today is an address that is 32-bits long. In an Ethernet local area network, however, addresses for attached devices are 48-bits long. - Page 41 Appendix B IP Address An IP address is a unique 32-bit address assigned to a computer and includes: • A network ID number identifying a network. • A host ID number identifying a computer on the network. All IP addresses have been divided into three smaller groups (classes) A, B and C •...
-
Page 42: Appendix Cip Netmask
Appendix C IP Netmask IP Netmask or Subnet Mask is a 32-bit pattern of ones and zeros used to determine network portion of an IP address from the host portion of the IP address. Subnet mask is a network ID that is created by borrowing bits from host portion of IP address and using them as part of a network ID. -
Page 43: Appendix Dascii Chart
Appendix D ASCII Chart ASCII Binary ASCII Binary Char No Parity Char No parity 00000000 01000000 00000001 01000000 00000010 01000010 00000011 01000011 00000100 01000100 00000101 01000101 00000110 01000110 00000111 01000111 00001000 01001000 00001001 01001001 00001010 01001010 00001011 01001011 00001100 01001100 00001101 01001101 00001110... -
Page 44: Ascii Chart Control Codes
Appendix D ASCII Chart Continuation 00101111 01101111 00110000 01110000 00110001 01110001 00110010 01110010 00110011 01110011 00110100 01110100 00110101 01110101 00110110 01110110 00110111 01110111 00111000 01111000 00111001 01111001 00111010 01111010 00111011 01111011 < 00111100 01111100 00111101 01111101 > 00111110 01111110 00111111 01111111 ASCII Control Codes ASCII Dec Hex Ctrl Key... -
Page 45: Part 7: Approvals Information
PART 7 APPROVALS INFORMATION 7.1 CE APPROVAL This product conforms to the EMC directive 89/336/EEC amended by 93/68/EEC, and with the European Low Voltage Directive 72/23/EEC. Electrical Safety EN61010-1:2001 Safety requirements for electrical equipment for measurement, control and laboratory. Basic Insulation Pollution Degree 2 Dielectric withstand Test per 1 min •... -
Page 46: Certificate Of Conformance
® 3-Point Certificate of Conformance Model Number: iTHX-M NEWPORT Electronics, Inc. certifies that the instrument referenced above has been fully inspected, tested and calibrated prior to shipment in accordance with the instruction manual supplied. NEWPORT Electronics further certifies that this instrument meets or exceeds all of the published electrical, mechanical and operational performance characteristics. - Page 47 Warranty/Disclaimer NEWPORT Electronics, Inc. warrants this unit to be free of defects in materials and workmanship for a period of one (1) year from the date of purchase. In addition to NEWPORT’s standard warranty period, NEWPORT Electronics will extend the warranty period for one (1) additional year if the warranty card enclosed with each instrument is returned to NEWPORT.
- Page 48 Newport Electronics GmbH Daimlerstrasse 26 • D-75392 Deckenpfronn • Germany TEL: 49 7056 9398-0 • FAX: 49 7056 9398-29 Toll Free: 0800 / 6397678 • www.newport.de • e-mail: sales@newport.de Newport Electronique S.A.R.L. 11, rue Jacques Cartier • 78280 Guyancourt • France TEL: +33 1 61 37 29 00 •...
