Cornerstone™ 260B
1/4m Monochromator Family
User's Manual
Family of Brands – ILX Lightwave
• New Focus™ • Ophir
• Corion • Richardson Gratings™ • Spectra-Physics
®
®
®
MCS260B, Rev C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cornerstone 260B and is the answer not in the manual?

Questions and answers

Related Manuals for Newport Cornerstone 260B

Summary of Contents for Newport Cornerstone 260B

  • Page 1 Cornerstone™ 260B 1/4m Monochromator Family User's Manual Family of Brands – ILX Lightwave • New Focus™ • Ophir • Corion • Richardson Gratings™ • Spectra-Physics ® ® ® MCS260B, Rev C...

  • Page 2: Table Of Contents

    MCS260B CORNERSTONE 260B MONOCHROMATORS TABLE OF CONTENTS GENERAL INFORMATION ........................5 SYMBOLS AND DEFINITIONS ..................... 6 GENERAL WARNINGS ......................7 ELECTRICAL HAZARDS ....................... 7 MECHANICAL HANDLING ....................8 OPTICS CARE AND HANDLING ................... 8 INTRODUCTION ..........................9 OPTICAL CONFIGURATION ....................9 STRAY LIGHT REJECTION ....................
  • Page 3 18.4 GRATING DISPERSION ...................... 73 18.5 GRATING ILLUMINATION AND RESOLUTION..............73 WARRANTY AND SERVICE ......................74 19.1 CONTACTING NEWPORT CORPORATION ..............74 19.2 REQUEST FOR ASSISTANCE / SERVICE ................. 75 19.3 REPAIR SERVICE ....................... 75 19.4 NON-WARRANTY REPAIR ....................75 19.5 WARRANTY REPAIR ......................
  • Page 4 CORNERSTONE 260B MONOCHROMATORS LIST OF FIGURES Figure 1: Optical Configurations of the Cornerstone 260B with Quad Grating Assembly......10 Figure 2: Optical configuration of the Cornerstone 260B with Dual Grating Assembly......10 Figure 3: Model numbering system......................11 Figure 4: Application Example: Quantum Efficiency Measurements.

  • Page 5: General Information

    Do not attempt to operate any system without reading all the information provided with each of the components. Please read all instructions that were provided prior to operation of the system. If there are any questions, please contact Newport Corp. or the representative through whom the system was purchased.

  • Page 6: Symbols And Definitions

    EUROPEAN UNION CE MARK The presence of the CE Mark on Newport Corporation equipment means that it has been designed, tested and certified as complying with all applicable European Union (CE) regulations and recommendations.

  • Page 7: General Warnings

    Make all connections to or from the instrument with the power off. The Cornerstone 260B requires DC voltage for operation, which is provided by an external power supply. This power supply has no user serviceable parts. Do not attempt to open the external power supply.

  • Page 8: Mechanical Handling

    MCS260B CORNERSTONE 260B MONOCHROMATORS 1.4 MECHANICAL HANDLING Avoid dropping, sudden shocks, or rough handling of the monochromator since this may cause the system to lose its calibration and may destroy the high precision drive components or optics. 1.5 OPTICS CARE AND HANDLING Do not touch any optical surfaces since this is likely to cause irreparable damage.

  • Page 9: Introduction

    Cornerstone family of monochromators. The Cornerstone 260B includes a utility program designed to run on a computer using the Microsoft Windows operating system. The simple, intuitive interface means that users can get up and running within minutes of opening the box.

  • Page 10: Stray Light Rejection

    MCS260B CORNERSTONE 260B MONOCHROMATORS Figure 1: Optical Configurations of the Cornerstone 260B with Quad Grating Assembly. Figure 2: Optical configuration of the Cornerstone 260B with Dual Grating Assembly. 2.2 STRAY LIGHT REJECTION Stray light may have a variety of origins. Its presence may be caused by a wide variety of design and manufacturing factors.

  • Page 11: Available Models

    MCS260B CORNERSTONE 260B MONOCHROMATORS Cornerstone 260B incorporates a sophisticated design, proven materials, and a quality manufacturing system to ensure high stray light rejection. The amount of stray light measured on top of true signal will depend on many experimental factors as well as the performance of the instrument.

  • Page 12: Typical Applications

    CORNERSTONE 260B MONOCHROMATORS 2.4 TYPICAL APPLICATIONS The applications for the Cornerstone 260B monochromator are practically limitless. Here we present one example. A quantum efficiency measurement system using an optically chopped light source used with a lock-in digital amplifier to extract small signal levels from background radiation.

  • Page 13: Initial Setup

    Inspect the shipping box for external signs of damage or mishandling. Inspect the contents for damage. If any item is missing or damaged, immediately contact the Newport representative from whom the system was purchased.

  • Page 14: Mounting Options

    The feet may be removed to secure the base plate to an inch or metric optical table. The most economical option is to use optical rods and rod holders to mount the Cornerstone 260B to an optical table or breadboard. On the monochromator’s mounting surface, four #1/4-20 threaded holes may be used to install standard optical rods.

  • Page 15: Electrical And Computer Connections

    Read all warnings before installing or operating this system. If there are any questions or concerns, contact Oriel Instruments or the regional sales representative for Newport. ELECTRICAL SHOCK Never attempt to open the lamp power supply or monochromator power adapter.

  • Page 16: Figure 6: Monochromator Connections

    MCS260B CORNERSTONE 260B MONOCHROMATORS Figure 6: Monochromator Connections. A USB cable (model 70044) and RS-232 and cable (model 70040) are included with each Cornerstone 260B. If using a commercially available USB-to-RS-232 converter cable, the driver for this cable must be installed before communication to the monochromator can be established.

  • Page 17: Shutter

    CORNERSTONE 260B MONOCHROMATORS 4 SHUTTER An electronic shutter is integrated into the Cornerstone 260B monochromator’s design. It is mounted inside the housing at the input port. This shutter is normally closed. The shutter is used to close the light path when light is not required. This allows the light source to remain on, and therefore remain warmed up, so that it continues to provide stable performance.

  • Page 18: Input And Output Slits

    To operate any monochromator, slits are required at the input and output port. The slit assemblies offered with the Cornerstone 260B all have 1.5-inch male flanges, allowing them to be easily connected to the wide variety of Oriel accessories and instruments.

  • Page 19: Micrometer Adjustable Slits

    MCS260B CORNERSTONE 260B MONOCHROMATORS 5.2 MICROMETER ADJUSTABLE SLITS µm) Micrometer adjustable slit assemblies are continuously variable from fully closed (4 to 3 mm width (Fig 10). A height adjustment slide allows variation in the height from 3 to 12 mm. Benefits of the micrometer adjustable slits are flexibility and high throughput.

  • Page 20: Figure 12: Shortest Micrometer Adjustable Slit Height

    MCS260B CORNERSTONE 260B MONOCHROMATORS The slit height is continuously adjustable. Pull the lever out for the shortest height (Fig 12). Push the slide in for the tallest height setting (Fig 13). Figure 12: Shortest Micrometer Adjustable Slit Height. Figure 13: Tallest Micrometer Adjustable Slit Height.

  • Page 21: Diffraction Gratings

    Diffraction gratings are used to spatially separate light of different wavelengths. They have replaced prisms in most fields of spectral analysis. Up to four gratings are installed into the Cornerstone 260B monochromator, depending upon the configuration selected. In general, the grating with the highest efficiency is chosen at a particular wavelength.

  • Page 22: Grating Types

    MCS260B CORNERSTONE 260B MONOCHROMATORS 6.1 GRATING TYPES Ruled grating masters are produced using a ruling engine with an extremely fine cutting tool. Holographic gratings (also called interference gratings) are produced by recording interference fringes in photoresist. The two different techniques cause some differences in performance.

  • Page 23: Grating Efficiency And Blazing

    MCS260B CORNERSTONE 260B MONOCHROMATORS 6.2 GRATING EFFICIENCY AND BLAZING Efficiency and its variation with wavelength and spectral order are important characteristics of a diffraction grating. For a reflection grating, efficiency is defined as the energy flow (power) of monochromatic light diffracted into the order being measured, relative either to the energy flow of the incident light (absolute efficiency) or to the energy flow of specular reflection from a polished mirror substrate coated with the same material (relative efficiency).

  • Page 24: Figure 17: Grating Efficiency Curve, Cornerstone 260B Monochromator Uv-Nir, High Resolution Quad Configuration (Cs260B-1 Models)

    MCS260B CORNERSTONE 260B MONOCHROMATORS Figure 17: Grating Efficiency Curve, Cornerstone 260B Monochromator UV-NIR, High Resolution Quad Configuration (CS260B-1 Models). Figure 18: Grating Efficiency Curve, Cornerstone 260B Monochromator UV-NIR, High Resolution Dual Configuration (CS260B-2 Models).

  • Page 25: Figure 19: Grating Efficiency Curve, Cornerstone 260B Monochromator Vis-Nir, Extended Range Configuration (Cs260B-3 Models)

    MCS260B CORNERSTONE 260B MONOCHROMATORS Figure 19: Grating Efficiency Curve, Cornerstone 260B Monochromator VIS-NIR, Extended Range Configuration (CS260B-3 Models). Figure 20: Grating Efficiency Curve, Cornerstone 260B Monochromator UV-SWIR, Extended Configuration (CS260B-Q Models).

  • Page 26: Polarization Effects

    S and P-polarization for optics where the plane of incidence rather than the grooves is used to define parallel and perpendicular. The graphs for the Cornerstone 260B configurations have one efficiency curve per grating. This is representative of 45-degree polarization, which is the average of the P-polarization and S- polarization efficiency curves.

  • Page 27: Figure 21: Available Diffraction Grating Options

    MCS260B CORNERSTONE 260B MONOCHROMATORS Model Grating Lines/mm Blaze Primary Wavelength Peak Type Wavelength (nm) Region Efficiency 74060B Ruled 2400 200 to 700 nm 74061B Holographic 1800 320 to 925 nm 74062B Holographic 1201.6 200 to 600 nm 74063B Ruled 1200...

  • Page 28: Monochromator Resolution

    Resolution is calculated for each grating at the grating's blaze wavelength, i.e. the wavelength with the greatest efficiency. Actual performance is determined by the monochromator wavelength accuracy, precision and calibration. Newport suggests having the monochromator recalibrated annually by a qualified service technician.

  • Page 29: Getting Light Into A Monochromator

    MCS260B CORNERSTONE 260B MONOCHROMATORS 8 GETTING LIGHT INTO A MONOCHROMATOR 8.1 ACCEPTANCE PYRAMID The figure below shows the optical path of the light input to the instrument. The monochromator has an acceptance pyramid, often described by an F/#. The position and dimensions of the internal optics determines the pyramid.

  • Page 30: F Number Matching

    CORNERSTONE 260B MONOCHROMATORS 8.2 F NUMBER MATCHING The Cornerstone 260B monochromator is an F/3.9 instrument. Without matching the F/# of the incoming light beam, stray light increases, and throughput of desired signal suffers. To illustrate this, the photos below show a fiber optic cable placed at the entrance of a monochromator. Fibers are typically F/2.

  • Page 31: Blocking Higher Order Radiation

    Erroneous measurements may be taken because what was thought to be a measurement with a single wavelength was a measurement using radiation at that wavelength – but contaminated with higher order radiation. Consider using Newport’s Colored-Glass Alternative Filters for blocking higher order diffraction.

  • Page 32: Filter Wheel

    The Cornerstone 260B is designed and manufactured to have errors of only a fraction of a millimeter in the focal distance. Positioning the filters externally, usually before the input slit, has only a slight effect on the light throughput.

  • Page 33: Communication Methods

    MCS260B CORNERSTONE 260B MONOCHROMATORS 10 COMMUNICATION METHODS In order to satisfy the needs of as many users as possible, the Cornerstone 260B is designed to be controlled from a variety of sources. 10.1 UTILITY SOFTWARE LabVIEW-based utility software is included at no extra cost with all Cornerstone models to control both the monochromator and filter wheel accessory.

  • Page 34: Hand Controller

    TracQ Basic is an application integrating Oriel monochromators with various detection instruments, such as the Newport Optical Power and Energy Meters, 1918-R, 1936-R and 2936-R, plus Oriel’s LIDA-SRS-KIT. Software prompts guide users through the measurement process.

  • Page 35: Low-Level Commands

    MCS260B CORNERSTONE 260B MONOCHROMATORS Figure 30: TracQ Basic Screens. 10.4 LOW-LEVEL COMMANDS A command set is provided for those wishing to create their own programming. A list of these commands is provided in Appendix I of this user’s manual. Commands are simple to use. For example, to query the wavelength, enter “WAVE?”...

  • Page 36: Grating Installation And Calibration

    When performing this procedure, it is necessary to use a light source with a known spectral line appearing within the operating range of the grating. Newport offers a number of pencil calibration lamps for this purpose, such as the model 6035 Hg lamp. Another line source such as a laser may also be used.

  • Page 37: Determining The Grating Calibration Factor

    MCS260B CORNERSTONE 260B MONOCHROMATORS 11.3 DETERMINING THE GRATING CALIBRATION FACTOR The following procedure allows advanced users to perform a two-point grating calibration. Procedure: 1. Select a radiation source that has at least two narrow spectral lines in the wavelength region of interest.

  • Page 38: Troubleshooting

    Cornerstone monochromator. If the tips in this section do not restore the instrument to working condition, contact Newport to arrange for technical support or repair. Contact information can be found in the Warranty and Service section of this user’s manual.

  • Page 39: Specifications

    MCS260B CORNERSTONE 260B MONOCHROMATORS 13 SPECIFICATIONS General Specifications Focal Length 260 mm F/3.9 Wavelength Selection Method Motorized Usable Wavelength Range 250 to 2500 nm, grating dependent Spectral Resolution Grating dispersion and slit width dependent Wavelength Accuracy ±0.50 nm Wavelength Step Resolution (Precision) ±0.0754 nm Stray Light 0.01%...
  • Page 40 MCS260B CORNERSTONE 260B MONOCHROMATORS Micrometer Adjustable Slit Specifications Width Range 4 μm to 3 mm Height Range 3 mm to 12 mm Repeatability ± 10 μm ± 10 μm (width from 4 μm to 250 um) Accuracy ± 5% (width from 250 μm to 3 mm)

  • Page 41: Dimensions

    MCS260B CORNERSTONE 260B MONOCHROMATORS 14 DIMENSIONS Figure 33: Cornerstone 260B Dimensions Figure 34: Micrometer Adjustable Slit Dimensions...

  • Page 42: Figure 35: Model 74104B Mounting Kit

    MCS260B CORNERSTONE 260B MONOCHROMATORS Figure 35: Model 74104B Mounting Kit...

  • Page 43: Appendix I: Remote Commands And Queries

    Commands and Queries may be sent to the CS260B’s RS-232 port using HyperTerminal, PuTTY, YAT, Newport’s MonoTerm, or other similar terminal-emulation programs. Connect a standard 9- pin PC serial port to the CS260B using a straight-through (not null modem) cable. Once the...

  • Page 44: Troubleshooting Rs-232

    MCS260B CORNERSTONE 260B MONOCHROMATORS 15.2 TROUBLESHOOTING RS-232 One of the most common problems when first connecting a PC to an RS-232 device is that the cable may swap the signals. The cable should be the straight-through type, and if you aren’t sure that it is, there are a couple of things you can try.

  • Page 45: Command And Query Syntax

    MCS260B CORNERSTONE 260B MONOCHROMATORS 15.3 COMMAND AND QUERY SYNTAX For the purposes of this discussion, communication with the instrument is divided into two types. Messages sent to the CS260B from the computer are called “Statements”, and messages received by the computer from the monochromator are called “Responses”. When communicating with the instrument, two types of Statements are used: “Commands”...

  • Page 46: Handshake Mode

    MCS260B CORNERSTONE 260B MONOCHROMATORS Queries If Echo is enabled, the CS260B echoes back all characters it receives on the RS-232 port. Additionally, it sends the response to the query. After sending a Query, the application must read back both the echo (if enabled) and the answer.
  • Page 47 MCS260B CORNERSTONE 260B MONOCHROMATORS Send : WAVE?[cr][lf] Response: WAVE?[cr][lf]500.01[cr][lf]00[cr][lf] Example (RS-232, echo off, handshake on): Send : WAVE?[cr][lf] Response: 500.01[cr][lf]00[cr][lf] For queries received on the USB port, the CS260B sends only the query response. The query response can be read back by itself.

  • Page 48: Cs260B Command Quick Reference Summary

    MCS260B CORNERSTONE 260B MONOCHROMATORS 15.6 CS260B COMMAND QUICK REFERENCE SUMMARY Command OVL/SEQ Query Hand Controller Key BANDPASS [value] BANDPASS? SHIFT BAND CALIBRATE [value] SHIFT CALIB ECHO [0/1] ECHO? ERROR? FILTER [f] FILTER? FILTER FILTER[f]LABEL [text] FILTER[f]LABEL? SHIFT LABEL | FILTER...

  • Page 49: Detailed Command Reference

    MCS260B CORNERSTONE 260B MONOCHROMATORS 15.7 DETAILED COMMAND REFERENCE This section describes the syntax, parameters, and functionality for every CS260B Statement. Some Statements appear with some upper-case and some lower-case letters. Upper case letters are required. For example, “GRATing” indicates that the CS260B will accept either the command “grat”...
  • Page 50 MCS260B CORNERSTONE 260B MONOCHROMATORS Command: CALIBRATE Purpose: Make a minor offset adjustment to the wavelength calibration. Use when installing new gratings, or at any point when the wavelength calibration is disrupted. Send this command to define the current position as the wavelength specified in the parameter.
  • Page 51 MCS260B CORNERSTONE 260B MONOCHROMATORS Command: FILTER Purpose: Change the filter wheel setting and move the filter wheel to that value. Parameter: An integer number from 1 to 6. Example: filter 2: rotate the wheel to filter 2. Default: Command: FILTER? Purpose: Query the current filter wheel position.
  • Page 52 MCS260B CORNERSTONE 260B MONOCHROMATORS Command: GOWAVE Purpose: Store the parameter as the new wavelength setting and rotate the currently-selected grating to the angle that causes the specified wavelength to appear at the output. Parameter: A floating-point number representing the desired wavelength in the currently-selected wavelength units.
  • Page 53 MCS260B CORNERSTONE 260B MONOCHROMATORS Command: GRATing Purpose: Store the grating setting and rotate the grating stage or turret to the desired grating. The stage will rotate to the location required for the new grating to pass the currently-selected wavelength to the output.
  • Page 54 MCS260B CORNERSTONE 260B MONOCHROMATORS Command: GRAT1LINES Purpose: Set the line spacing for grating 1 in lines per mm. Parameter: An integer number from 0 (mirror) to 4000. Example: grat1lines 600: set the lines/mm for grating 1 to 600. Default: 600.
  • Page 55 MCS260B CORNERSTONE 260B MONOCHROMATORS Command: IDLE? See if any operations are pending. See the section entitled “Command Purpose: Synchronization”. Example: IDLE? E.g. response 1: no operations are pending. E.g. response 0: an operation is pending. Command: INFO? Purpose: Query for basic instrument information. The response is: “Oriel Instruments, Model 74000 Cornerstone 260,SNXXX,V.VV”...
  • Page 56 MCS260B CORNERSTONE 260B MONOCHROMATORS Command: OUTPORT Purpose: Select the output port through which light will exit the CS260B. Port numbering: 1 is the Axial port (where light exits when no flip mirror option is installed), 2 is Lateral port. Light exits the lateral port when the flip mirror is extended.
  • Page 57 MCS260B CORNERSTONE 260B MONOCHROMATORS Command: SHUTTER Purpose: Open or close the shutter on the input port. 1 or the character ‘O’ to open the shutter, 0 (zero) or ‘C’ to close. Parameter: Example: shutter 1: open the shutter. Example: shutter c: close the shutter.
  • Page 58 MCS260B CORNERSTONE 260B MONOCHROMATORS Command: SLOWSTEP Purpose: Slowly step the grating rotation stage a desired number of steps. Parameter: The number of steps to take. The allowed range is -10000 to 10000. If no parameter is given, the value previously specified by the “stepsize”...
  • Page 59 MCS260B CORNERSTONE 260B MONOCHROMATORS Command: UNITS Purpose: Specify wavelength units. Wavelength values will be displayed, reported and accepted in these units. A string representing the units. Allowable strings: ‘nm’, ‘um’, and ‘wn’. Parameter: Example: units nm: set wavelength units to nanometers...
  • Page 60 MCS260B CORNERSTONE 260B MONOCHROMATORS Command: *IDN? Purpose: Query the CS260B’s identification information. The comma-separated fields in the response are: Manufacturer ID, instrument, serial number, and firmware version. Example: *IDN? E.g. response: Newport Corp, CS260B,1234,2.01 Command: *ESR? Purpose: Query the contents of the ESR register.

  • Page 61: Command Synchronization

    MCS260B CORNERSTONE 260B MONOCHROMATORS 15.8 COMMAND SYNCHRONIZATION The CS260B has commands that allow an application to coordinate some of its operations. For example, a customer’s application may need to wait for the grating rotation stage to reach a wavelength before it begins to read a detector. The pseudo-code for this would be: •...

  • Page 62: Error Codes

    MCS260B CORNERSTONE 260B MONOCHROMATORS • Read Event Status Register (use *ESR? query); if bit 0 is not set, read it again. Continue until bit 0 is set. • Read detector. The fourth synchronization operation, also adopted from IEEE488, is only for synchronizing CS260B internal operations.
  • Page 63 MCS260B CORNERSTONE 260B MONOCHROMATORS gowave 9999 -224, Illegal Parameter Value Requested wavelength too high gowave 765 0, No Error No problem 501, Filter Wheel Missing No filter wheel detected at power- Here is the list of the error codes and strings that the CS260B can detect and report. Note that some codes are positive and some are negative.
  • Page 64 MCS260B CORNERSTONE 260B MONOCHROMATORS Cannot Reach Typically, when grating-change command Wavelength results in unobtainable wavelength. Grating Halted Caused by grating or wavelength command during firmware upgrade. Also, by rotation stage problem. Filter Wheel Missing Filter wheel not detected at power-up.

  • Page 65: Appendix Ii: Using The Hand Controller

    Connect the hand controller to a powered Cornerstone 260B. The order of connection and power is not important. If it is connected when the Cornerstone 260B powers up, some information is displayed briefly such as serial number and firmware version (of the Cornerstone 260B).

  • Page 66: Key Reference

    MCS260B CORNERSTONE 260B MONOCHROMATORS 16.3 KEY REFERENCE These commands are listed based on the key locations from the top of the controller to the bottom and left to right. ABORT If you accidentally press a function key or enter a bad parameter you may press the ABORT key to clear that command before it executes.
  • Page 67 This key (located directly above GRAT) provides access to the grating label. The label is an eight character alpha-numeric field that is used for information only. Newport assigns the grating blaze wavelength to the label during calibration. (You can also change the label using the “grat1label”...
  • Page 68 MCS260B CORNERSTONE 260B MONOCHROMATORS seconds of starting a command entry, the entry times out and terminates.

  • Page 69: Appendix Iii: Usb Operation

    The driver for the USBTMC is included with LabView, so LabView users don’t need to install anything else to be able to communicate with the Cornerstone 260B. The MonoTerm software is written in LabView and the source code is shipped with the instrument. It can be used as example code when learning how to connect to the Cornerstone 260B.

  • Page 70: Appendix Iv: Grating Physics Tutorial

    MCS260B CORNERSTONE 260B MONOCHROMATORS 18 APPENDIX IV: GRATING PHYSICS TUTORIAL 18.1 THE GRATING EQUATION A typical diffraction grating consists of a substrate, usually of an “optical material”, with a large number of parallel grooves ruled or replicated in its surface and overcoated with a reflecting material such as aluminum.

  • Page 71: The Grating Equation In Practice

    MCS260B CORNERSTONE 260B MONOCHROMATORS 18.2 THE GRATING EQUATION IN PRACTICE When a parallel beam of monochromatic light is incident on a grating, the light is diffracted from the grating in directions corresponding to m = -2, -1, 0, 1, 2, 3, etc. When a parallel beam of polychromatic light is incident on a grating then the light is dispersed so that each wavelength satisfies the grating equation.

  • Page 72: Grating Order

    MCS260B CORNERSTONE 260B MONOCHROMATORS 18.3 GRATING ORDER It is important to note the sign of “m” is given by either form of the grating equation and can be positive or negative. In a monochromator, the angles I and D are determined by the rotational position of the grating.

  • Page 73: Grating Dispersion

    MCS260B CORNERSTONE 260B MONOCHROMATORS 18.4 GRATING DISPERSION If we fix the angle I in the grating equation and differentiate with respect to wavelength we get: a cos D δD = m δλ Thus: δD a cos D δλ δD/δλ is the angular dispersion or change of diffraction angle corresponding to a small change in wavelength.

  • Page 74: Warranty And Service

    Oriel Instruments belongs to Newport Corporation's family of brands. Thanks to a steadfast commitment to quality, innovation, hard work and customer care, Newport is trusted the world over as the complete source for all photonics and laser technology and equipment.

  • Page 75: Request For Assistance / Service

    Newport's discretion. Newport is not responsible for damage occurring in transit. The Owner of the product bears all risk of loss or damage to the returned Products until delivery at Newport’s facility. Newport is not responsible for product damage once it has left the facility after repair or replacement has been completed.

  • Page 76: Warranty Repair

    Except as otherwise expressly stated in Newport’s quote or in the current operating manual or other written guarantee for any of the Products, Newport warrants that, for the period of time set forth below with respect to each Product or component type (the "Warranty Period"), the Products sold hereunder will be free from defects in material and workmanship, and will conform to the applicable specifications, under normal use and service when correctly installed and maintained.

  • Page 77: Loaner / Demo Material

    The Newport programs and all materials furnished or produced in connection with them ("Related Materials") contain trade secrets of Newport and are for use only in the manner expressly permitted. Newport claims and reserves all rights and benefits afforded under law in the Programs provided by Newport Corporation.
