Icom ID-31A PLUS Advanced Manual page 157

11
MENU SCREEN
GPS items
Alarm Area (RX/Memory)
MENU > GPS > GPS Alarm> Alarm Area (RX/
Memory)
Select the GPS active alarm range�
When a target enters in the active alarm range, the
GPS Alarm sounds and the GPS alarm icon blinks�
L When Alarm Select is set to "RX" or "Memory," this
setting is enabled�
• Limited: The transceiver sounds 3 beeps and the
GPS Alarm icon blinks when the target
enters the 500 meter range�
• Extended: The transceiver sounds 3 beeps and the
GPS Alarm icon blinks when the target
enters the 1 kilometer range�
• Both: The transceiver sounds a beep and the
GPS Alarm icon blinks when the target
enters the 1 kilometer range, and sounds
3 beeps and the icon blinks when it enters
the 500 meter range�
When the target exits the 500 meter
range, but is still in the 1 kilometer range,
the icon continues to blink, but no beeps
sound�
Example:
When a target station enters in the active alarm range
(500 meter or 1 kilometer range, depending on the
setting), the GPS Alarm sounds and the GPS Alarm
icon blinks�
Extended range
Approximately 1 km, 1094 Y
Approximately 500 m, 547 Y
Your location
Target station
Sounds a beep.
(Default: Both)
Limited range
Sounds 3 beeps.
GPS Logger
MENU > GPS > GPS Logger > GPS Logger
Turn the GPS Logger function ON or OFF�
This function logs the position, altitude, course, speed,
and number of satellites being used�
L BE SURE to insert a microSD card�
L When GPS select is set to "OFF" or "Manual," this
function does not save the log�
• OFF: Turns OFF the function�
• ON: The transceiver automatically logs GPS data�
Once this function is turned ON, the GPS data
will be continuously logged until the function
is turned OFF, even if the transceiver is turned
OFF, then ON again�
TIP: The log data is saved on the microSD card�
The file name is automatically created, as shown
below:
• Log start date and time: 31st October 2017
• File name:
Record Interval
MENU > GPS > GPS Logger > Record Interval
Set the GPS Logger function record interval to 1, 5,
10, 30, or 60 seconds�
Record Sentence
(Default: ✔ RMC/ ✔ GGA/ ✔ VTG/ ✔ GSA)
MENU > GPS > GPS Logger > Record Sentence
N
Set the GPS Logger function record sentence to
RMC, GGA, VTG, or GSA�
• Displays "✓" when the sentence is set�
NOTE: Select at least one sentence, otherwise an
error beep will sound�
<<GPS Logger Only>>
MENU > GPS > GPS Logger > <<GPS Logger
Only>>
You can turn ON the GPS Logger Only mode ON�
In this mode, only the GPS Logger is functioning and
the transceiver does not transmit or receive� (p� 5-32)
Information
L
• BE SURE to insert a microSD card�
• Set GPS Select to "Internal GPS," or "External GPS�"
(p� 11-9)
• To cancel the mode, reboot the transceiver�
11-14
(Default: ON)
15:30:00
20171031_153000�log
(Default: 5sec)
