1 In the Mobility Domain list, select the Mobility Domain that contains the
2 In the Radio Profile list, select the radio profile used for this coverage
3 In the Wiring Closet list, select the wiring closet that contains the WX
4 In the Redundant Wiring Closet list, select the wiring closet that will
5 Click Finish to complete the wizard and create the coverage area.
Editing Coverage
Areas
1 Display the floor plan in the Content panel.
2 In the Task List panel, click Floor.
3 Under Edit Floor, click Coverage Areas. The Coverage Areas List dialog is
Specifying Mobility Domain, Radio Profile, and Wiring Closet
Associations
To specify association information for the coverage area:
MAPs used for this coverage area.
area.
The profiles available depend on the Mobility Domain you selected in
step 1. For a policy to appear in this list, you must have already
configured a policy and selected the Wireless Service Profiles and Radio
Profiles checkbox in the Policy Areas dialog.
The policy you select applies to all radios associated with the coverage
area. If you type the name of a radio profile that does not already exist,
3WXM creates it.
switch or switches to be connected to the shared MAP access points.
If the MAPs will be directly connected to WX switches, a wiring closet is
required. If all the MAPs in the coverage area will be indirectly connected
to WX switches through the network, a wiring closet is not required.
provide redundant connection to the MAP access points. This is required
for directly connected MAPs, if you require the MAPs to have redundant
connections. Otherwise, this is not required.
Only AP models that have two Ethernet ports can support redundant
direct connections. However, models with one Ethernet port can support
redundant distributed connections.
To edit existing coverage areas:
displayed.
Defining Wireless Coverage Areas 127
