452 C 16: M
HAPTER ONITORING THE
N
ETWORK
2 Select the scope to monitor from the list on the left side of the dialog
box.
3 Select the specific object(s) to monitor from the list on the right side of
the dialog box.
To select multiple contiguous objects, click Shift while selecting.
To select multiple noncontiguous objects, click Ctrl while selecting.
4 Select the statistic type from the Monitoring Options box:
Ethernet Statistics
Ethernet Errors
EtherStats (packets per second by different packet lengths)
Radio Statistics
5 Select the polling interval from the Poll Interval box. The intervals
available depend on the scope and statistic type you selected.
6 Click Start Monitoring. The Statistics dialog for your scope selection
appears.
