Viewing the
Configured MAPs
1 Select the Configuration tool bar option.
2 In the Organizer panel, click the plus sign next to the WX switch.
3 Click the plus sign next to Wireless.
4 Select Access Points.
Creating a
Distributed MAP
1 Access the Create Distributed AP wizard:
To view the configured MAPs:
The MAPs that are configured on the WX switch appear in the Content
panel. The radio settings appear in the Content panel. Each row in the
table shows settings for an individual MAP.
To display all settings for a MAP, select the MAP and click Properties.
A MAP can connect to the wired network through a direct 10/100
Ethernet connection to a WX or indirectly through other Layer 2 or
Layer 3 wired networking devices. Configure a Distributed MAP for each
indirectly connected MAP.
Table 20 lists how many MAPs you can configure on a WX switch, and
how many MAPs a switch can boot. The numbers are for directly
connected and Distributed MAPs combined.
Table 20 Maximum MAPs Supported Per Switch
WX Switch Model
WX4400
WX1200
WXR100
WX2200
For a MAP that is directly connected to the WX, configure a MAP port
instead. (For information, see "Configuring a Directly Connected MAP"
on page 277.)
To create a distributed MAP
a Select the Configuration tool bar option.
b In the Organizer panel, click the plus sign next to the WX switch.
Viewing and Configuring MAPs
Maximum Configured
300
30
8
300
Maximum Booted
24, 48, 72, 96, 120,
depending on the license.
12
3
24, 48, 72, 96, 120
275
