Refreshing Rf Trend Data; Accessing Realtime Performance Statistics - 3Com WX1200 Reference Manual

Refreshing RF Trend
Data
Accessing Realtime
Performance
Statistics
To change how you view data values, select Absolute to see absolute
values or Deltas to see rate-of-change values.
The data displayed in the RF Trends view is refreshed at regular intervals
(every 5 minutes by default). The data is refreshed based on the specified
polling interval. (See "Changing Monitoring Settings" on page 503.) You
can also refresh the data on demand.
To refresh the data on demand, click the
Trends view toolbar.
In addition to information supplied by 3WXM's monitoring features, you
can access performance statistics directly from the network.
To access performance statistics from the network
1 Do one of the following:
Select Tools > Performance Monitor from the toolbar in the main
3WXM window. The Performance Monitoring dialog box appears.
Go to step 4.
Select an object in the Organizer panel, then right-click and select
Performance Statistics and the type of statistics to monitor from the
menu. The Performance Monitoring dialog box appears, with the
scope and statistic type selected. Go to step 5.
In the Client Monitor window, click
to "Viewing Performance Data" on page 453.

Accessing Realtime Performance Statistics

(refresh) icon on the RF
on the window's toolbar. Go
451
