Satec EM132 Installation And Operation Manual page 162

‎ A ppendix Parameters for
E
ANG I1
I1 H01 ANG
I1 H02 ANG
...
I1 H40 ANG
ANG I2
I2 H01 ANG
I2 H02 ANG
...
I2 H40 ANG
ANG I3
I3 H01 ANG
I3 H02 ANG
...
I3 H40 ANG
H1 PHASE
V1 H01
V2 H01
V3 H01
I1 H01
I2 H01
I3 H01
kW L1 H01
kW L2 H01
kW L3 H01
kvar L1 H01
kvar L2 H01
kvar L3 H01
kVA L1 H01
kVA L2 H01
kVA L3 H01
PF L1 H01
PF L2 H01
PF L3 H01
HRM TOT POW
kW H01
kvar H01
kVA H01
PF H01
MIN PHASE
V1 MIN
V2 MIN
V3 MIN
I1 MIN
I2 MIN
I3 MIN
MIN TOTAL
kW MIN
kvar MIN
kVA MIN
162
Data Monitoring and Logging
Designation
I1 Harmonic Angles
H01 Harmonic angle
H02 Harmonic angle
...
H40 Harmonic angle
I2 Harmonic Angles
H01 Harmonic angle
H02 Harmonic angle
...
H40 Harmonic angle
I3 Harmonic Angles
H01 Harmonic angle
H02 Harmonic angle
...
H40 Harmonic angle
Fundamental (H01) Phase Values
V1/V12 Voltage
V2/V23 Voltage
V3/V31 Voltage
I1 Current
I2 Current
I3 Current
kW L1
kW L2
kW L3
kvar L1
kvar L2
kvar L3
kVA L1
kVA L2
kVA L3
Power factor L1
Power factor L2
Power factor L3
Fundamental and Harmonic Total Power Values
Total fundamental kW
Total fundamental kvar
Total fundamental kVA
Total fundamental PF
Minimum 1-Cycle Phase Values
V1/V12 Voltage
V2/V23 Voltage
V3/V31 Voltage
I1 Current
I2 Current
I3 Current
Minimum 1-Cycle Total Values
Total kW
Total kvar
Total kVA
Description
EH
EH
EH
1
1
1
1
1
1
EM13x Series SMART MULTIFUNCTION METER
