‎ A ppendix Setpoint Triggers
D
Appendix D
Actions
Table 25: Setpoint Triggers
Designation
NONE
STAT INP #1 ON
STAT INP #2 ON
STAT INP #3 ON
STAT INP #4 ON
STAT INP #5 ON
STAT INP #6 ON
STAT INP #1 OFF
STAT INP #2 OFF
STAT INP #3 OFF
STAT INP #4 OFF
STAT INP #5 OFF
STAT INP #6 OFF
RELAY #1 ON
RELAY #2 ON
RELAY #3 ON
RELAY #1 OFF
RELAY #2 OFF
RELAY #3 OFF
POS PHASE REVERSAL
NEG PHASE REVERSAL
HI VOLT RT
LO VOLT RT
HI AMPS RT
LO AMPS RT
HI V THD
HI I THD
HI KF RT
HI I TDD
HI FREQ RT
LO FREQ RT
HI V UNB% RT
HI I UNB% RT
HI I1 AVR
HI I2 AVR
HI I3 AVR
LO I1 AVR
LO I2 AVR
154
and Actions
Setpoint Triggers and
None (condition is not active)
Status Inputs
Status input #1 ON
Status input #2 ON
Status input #3 ON
Status input #4 ON
Status input #5 ON
Status input #6 ON
Status input #1 OFF
Status input #2 OFF
Status input #3 OFF
Status input #4 OFF
Status input #5 OFF
Status input #6 OFF
Relays
Relay #1 ON
Relay #2 ON
Relay #3 ON
Relay #1 OFF
Relay #2 OFF
Relay #3 OFF
Phase Reversal
Positive phase rotation reversal
Negative phase rotation reversal
Low/High 1-Cycle Values on any Phase
1 High voltage
1 Low voltage
High current
Low current
2 High voltage THD
2 High current THD
High K-Factor
High current TDD
1-Cycle Auxiliary Values
High frequency
Low frequency
1 High voltage unbalance
High current unbalance
1-Sec Phase Values
High I1 current
High I2 current
High I3 current
Low I1 current
Low I2 current
Description
EM13x Series SMART MULTIFUNCTION METER
