Receiving and Unpacking Requirements

Dimension
Weight
Oracle Server X7-2L:
Dimension
Width
Depth
Height
Weight

Receiving and Unpacking Requirements

When the server is unloaded at your site:
Leave the server in its shipping carton until it arrives at its installation location.
■
Use a separate area to remove the packaging material to reduce particle contamination
■
before the server is taken to the data center.
Ensure that there is enough clearance and clear pathways to move the server from the
■
unpacking area to the installation location.
Ensure the entire access route to the installation site is free of raised-pattern flooring that
■
causes vibration.

Rack Space Requirements

The Oracle Server X7-2 is a 1 rack unit (1U) server. Oracle Server X7-2L is a 2U server. For
physical dimensions, see
You can install the server into a four-post rack cabinet that conforms to ANSI/EIA 310-D-1992
or IEC 60297 standards, such as Oracle Rack Cabinet 1242 or Sun Rack II 1242. See
Compatibility" on page
The minimum ceiling height for the cabinet is 230 cm (90 inches), measured from the true
floor or raised floor, whichever is higher. An additional 91.4 cm (36 inches) of ceiling height is
required for top clearance. The space above the cabinet and its surroundings must not restrict
14 Oracle Servers X7-2 and X7-2L Installation Guide • October 2017
Server Specification
Fully populated server
Server Specification
Server chassis
Maximum overall
2-rack unit (2U) nominal
Fully populated server
"Server Physical Specifications" on page
41.
Measurement
40 lbs (18.1 kg)
Measurements
48.2 cm ( 18.9 inches)
75.9 cm (29.9 inches)
8.69 cm (3.42 inches)
64 lbs (29.03 kg)
13.
"Rack
