Identifying Components

These topics identify key components of the server, including major boards and internal system
cables, as well as front and rear panel features.
"Front Panel Components (Service)" on page 13
■
"Rear Panel Components (Service)" on page 15
■
"Internal Component Locations" on page 16
■
"Server Block Diagram" on page 19
■
Related Information
"Detecting and Managing Faults" on page 23
■
"Preparing for Service" on page 41
■

Front Panel Components (Service)

The following figure shows the layout of the server front panel, including the power and server
locator buttons and the various status and fault LEDs.
Note -
equipped), and the two front USB ports.
The front panel also provides access to internal drives, the removable media drive (if
Identifying Components 13
