Install a Fan Module
also perform this procedure using cold service. Optional steps for partially extending the server
from the rack are included in this procedure.
To view a video of replacing a fan module, see
Tip -
videos/E58906/fanreplace.html.
For serviceability considerations, see
■
Before You Begin
For fan module designation information, see
■
For instructions on removing a fan module, see
■
If you are installing a replacement fan module for one that has failed, check the
1.
indicator of the failed fan slot to ensure the fault indicator is no longer lit.
This is necessary to ensure the indicator status is cleared before you insert the new fan. See
"Fan Module Reference" on page 120
Orient the fan module so the connector on the bottom of the module is aligned
2.
with the connector on the inside of the slot and all keying and labeling are
correctly positioned.
118 Sun Server X4-4 Service Manual • October 2015
http://docs.oracle.com/cd/E38212_01/
"Component Serviceability" on page
"Component Designations" on page
"Remove a Fan Module" on page
for fan module indicator locations.
66.
69.
115.
