Remove a PCIe Slot Filler Panel

Remove a PCIe Slot Filler Panel
When servicing the components in this section, unplug the AC power cords and use ESD
protection.
Caution -
removing or installing expansion cards. You must disconnect the power cables before
performing this procedure.
1. Prepare for service. See
Locate the PCIe card filler panel that you want to remove.
2.
See "Server Back Panel Features" on page 20
locations.
Disengage the PCIe slot crossbar from its locked position and rotate the
3.
crossbar into an upright position.
4. Remove the PCIe card filler panel from the PCIe slot.
Caution -
replace it with another filler panel or a PCIe card; otherwise, the server might overheat due to
improper airflow.
"Install a PCIe Card" on page 151
■
Next Steps

Remove a PCIe Card

When servicing the components in this section, unplug the AC power cords and use ESD
protection.
148 Sun Server X4-4 Service Manual • October 2015
Component damage. Ensure that all power is removed from the server before
"Prepare the Server for Cold Service" on page
Server over temperature. Whenever you remove a PCIe card filler panel, you should
for information about PCIe slots and their
90.
