You must replicate this same DIMM population configuration on the replacement card.
The slots are color coded (for more information, see
Reference" on page
Ensure that you replicate the same DIMM configuration on the replacement card.
Note -
5. Transfer the DIMMs from the slots on the faulty MR card to the same slots on the
replacement card:
Transfer the DIMMs from the faulty card to the replacement card one at a time.
Tip -
a. Remove a DIMM from the faulty MR card. See
DIMM" on page
Install the DIMM on the replacement card. See
b.
DIMM" on page
c. Repeat the above steps until all DIMMs are transferred from the faulty card
to the replacement card.
6. Install the MR card. See
Prepare the server for operation. See
7.
Operation" on page

Remove a Memory Riser Card

When servicing the components in this section, unplug the AC power cords and use ESD
protection.
Use this procedure to remove a memory riser (MR) card to:
"Replace a Faulty DIMM" on page 129
■
141).
134.
136.
"Install a Memory Riser Card" on page
"Prepare the Server for
227.
Remove a Memory Riser Card
"Memory Riser Card and DIMM
"Remove a
"Install a
138.
Servicing CRU Components 131
