Replace the Motherboard (FRU)
25. Install the air divider by aligning it with its guide and lowering it into the server.
Ensure that the flanges on the divider enter their respective slots on the side
wall and that the plunger for the Fault Remind button is aligned with the button
on the motherboard.
26. Connect all cables from the power supply backplane, disk drive backplane, and
fan board to the motherboard.
27. Install all memory risers.
See"Install a Memory Riser Card" on page
For a two-CPU system, install the air baffle, ensuring that the foot on the front of
28.
the baffle is under the fan board ribbon cable.
29. Install all PCIe cards.
See "Install a PCIe Card" on page
30. Install the SP card. See
Install the power supply backplane cover plate.
31.
Note -
32. Prepare the server for operation. See
Operation" on page
Note -
need to be reprogrammed by authorized service personnel with the correct product serial
number.
226 Sun Server X4-4 Service Manual • October 2015
"Install the SP Card (FRU)" on page
Do not route the cables on the power supply backplane cover plate.
227.
The product serial number used for service entitlement and warranty coverage might
138.
151.
"Prepare the Server for
217.
