218
F1C ENGINE
TIGHTENING TORQUE
PART
PART
Six-lobe screw (M15x1.5 L 193) for cylinder head internal fastening
First stage: pre-tightening
Second stage: angle
Third stage: angle
Six-lobe screw (M12x1.5 L 165) for cylinder head side fastening
First stage: pre-tightening
Second stage: angle
Third stage: angle
Six-lobe screw (M8x1.25 L 117/58) for chain compartment side fastening (cylinder head)
R 1/2"bevel threaded cap with socket head
R 3/8" bevel threaded cap with socket head
R 1/8" bevel threaded cap with socket head
R 1/4" bevel threaded cap with socket head
M26x1.5 threaded screw tap
Screw with flange M6x1 for camshaft rear cover fastening
Screw with flange M6x1 for camshaft shoulder plate fastening
Socket head screw with flange M8x1.25 L 30/40/77/100 for over-head fastening
M14x1.5 L 10 threaded screw tap
Cap bolt socket screw (M6x1x25) for camshaft drive cover fastening
Flanged nut (M6x1) for camshaft drive cover fastening
M12x1.5 L 125 inner fastening screw for lower cylinder block
First stage: pre-tightening
Second stage: angle
Third stage: angle
M8x1.25 L 77.5/40 outer fastening screw for lower cylinder block
Socket head screw with flange M11x1.25x49 for connecting rod cap fastening
Preliminary torque
Second stage: angle
Socket head screw with flange M12x1.25x52,5 for engine flywheel fastening
Preliminary torque
Second stage: angle
Six-lobe socket screw (M6x1x15) for securing the phonic wheel to the drive shaft
Connection M10x1 for piston cooling nozzle
Tapered threaded cap with socket head (R 3/8"x10)
TE flanged screw (M20x1.5x58) for securing the camping pulley to the drive shaft
Bevel cap R 1/8 x 8
Water draining plug M14x1.5 L10
Pipe union on block for oil return from turbocharger G 3/8" x 12
Suction rose M6x1 fastening screw
Socket head nut with flange M8x1.25 for depressor — oil pump unit support fastening
Pin (M12x1.5x35) for oil pump/vacuum pump assembly control
Male threaded cap (M26x1.5)
Connection (R 1/4") for oil delivery to the turboblower
Socket head screw with flange M8x1.5 L35 for oil sump retaining frame fastening
Threaded cap with O-ring (M22x1.5 L10)
Socket head screw with flange M8x1.25 L60 for depressor - oil pump unit fastening
Flanged, hexagon nut (M8x1.25) for power steering pump support fastening
Base - March 2006
D
E
4
AILY
URO
TORQUE
Nm
kgm
130
13
90º
90º
65
6,5
90º
60º
25
2,5
40
4
29
2,9
7
0,7
9
0,9
50
5
10
1
10
1
25
2,5
25
2,5
10
1
10
1
50 ± 5
5 ± 0,5
60º ± 2,5º
60º ± 2,5º
26
2,6
50
5
70°
30
3
90°
15
1,5
25
2,5
40
4
350
35
7
0,7
25
2,5
50
5
10
1
25
2,5
130
13
40
4
40
4
25
2,5
50 ±10
5 ±1
25
2,5
25
2,5
Print 603.93.651
