Avaya IP Office Basic Edition Manual page 85

ETR 18D/ETR 34D Phone
1. At either or the first two extensions on the system, press Feature 0 0 followed by two presses of the first
intercom or call appearance button.
2. System Administration: is shown on the display.
3. Dial #203. The phone displays Co Disconnect Time.
4. At the Line: prompt, enter the two-digit number of the line for which you are adjusting the hold disconnect time.
5. The current hold disconnect time for the line is displayed.
6. Enter then option required between 1 to 7.
·
01 = 300 msec
·
02 = 350 msec
·
Exit programming by pressing Feature 00. You can also exit programming mode by lifting the handset, then
placing it back in the cradle.
Phone Based Administration
IP Office Basic Edition
· ·
03 = 400 msec 05 = 500 msec (default)
· ·
04 = 450 msec 06 = 550 msec
Comments on this document? infodev@avaya.com
Line Settings: CO Disconnect Time
·
07 = 600 msec
- Issue 6a (Thursday, February 22, 2018)
Page 85
