M7324N - Avaya IP Office Basic Edition Manual

1.5.8 M7324N

This type of phone can be used for system, centralized and personal administration functions covered by this document.
For system and centralized administration, the phone must be connected to one of the first two extension ports on the
system.
Button Numbering
The diagram below indicates the button functions during normal phone operation. The double digit numbers are the
button numbering for programmable buttons.
Hold Feature
1 2
4 5
7 8
* 0
– Volume
·
For systems running in key system mode, the first two programmable buttons, 01 and 02, are fixed as Intercom
1 and Intercom 2 buttons. Line buttons, based on the
trunks installed in the system, are assigned from buttons 23 downwards and then button 24 upwards.
·
For systems running in PBX system mode, the first three buttons, 01 to 03, are fixed as call appearance buttons.
Phone Based Administration
IP Office Basic Edition
Display
SK1 SK2
Release
3
6
9
#
+
