Avaya IP Office Basic Edition Manual page 296

17. System Maintenance
The functions in this section are not shown when browsing the menu of system administration options on a phone.
Instead they are only displayed when the appropriate code is entered in the menu.
·
Copy Extension Settings
Copy the user settings (except name and number) from one extension to another of the same type.
·
Remote Administration Password
Change the password used for PC access to the system configuration settings.
·
Backup the Configuration
Backup the current configuration.
·
Restore the Configuration
Copy a previous backup of the configuration file from a card in the Optional SD slot, to the System SD card and
restart the system with the new configuration.
·
System Copy
305
Copy the System SD card files to the Optional SD card.
·
System Default
307
Restart the system and return all settings to their defaults.
·
System Reset
308
Save the system settings and restart the system.
·
System Shutdown
Save the system settings and shutdown the system for maintenance.
·
System Upgrade
Copy new software from the Optional SD card to the System SD card and then restart the system using the new
software.
·
Switch SSL VPN Services On/Off
If the system has been configured for support by an SSL VPN service link, you can turn the link on or off.
Other Functions
The following settings affect system operation. These functions should typically only be performed when a system is first
installed:
·
67
System Mode
This setting is used to switch the system between key system mode and PBX system mode.
·
System Numbering
Set whether the system should use 2-digit or 3-digit extension numbering.
·
System Locale
69
Set the locale (country) that the system is installed in. This value adjusts a range of hidden trunks settings and the
default system language.
·
System Language
Set the default language for all extensions. The
SD Cards
The phone system has slots for SD cards which are used to store various files needed by the phone system. The System
SD slot must always contain an Avaya IP Office Basic Edition SD card.
Cards can be inserted while the system is running. However cards should only be removed while the system is shutdown.
This ensures that the card is not removed while files are being written to the card as that could cause corruption of those
files.
Phone Based Administration
IP Office Basic Edition
297
298
301
303
309
310
314
68
71
Comments on this document? infodev@avaya.com
display language for individual extensions can be changed.
150
- Issue 6a (Thursday, February 22, 2018)
Page 296
