4.3 Line Coverage Extension

When an incoming call arrives on a line, it is presented to all extensions that have a
for that line. However for call coverage, VMS coverage and call forwarding it can be set to follow the settings of the
extension set below as the line's coverage extension. This does not apply if the line is assigned to ring into the operator
group, a hunt group or a calling group.
1408/1416/9504/9508 Phone
1. At either of the first two extensions on the system, press Admin.
·
To do the above during a call, you may need to press the
option. If you access phone administration during a call, only the
buttons still affect the connected call.
2. Use the up or down
Select.
3. Use the up or down
·
Alternatively, dial # and the
4. Use the up or down
press Select.
5. At the Line: prompt, enter the desired line number 01 to 64.
6. At the Extension: prompt enter the covering extension for the line. Use the
toggle through the extensions. Press Clear to remove to setting.
7. Use the up or down
·
Exit programming by pressing
M7324/M7324N/M7310/M7310N/T7316/T7316E Phone
1. At either of the first two extensions on the system, press
·
If the system has a
2. The phone displays System Admin.
3. Dial #208. The phone displays Line Coverage Extension.
4. At the Line: prompt, enter the desired line number 01 to 64.
5. At the Extension: prompt enter the covering extension for the line.
·
Alternatively use the Next Data or Previous Data buttons to change the setting or press Remove to return
to the default setting.
·
To exit phone based administration at any time, press the Release button. To select a different process use the
Next Procedure or Previous Procedure buttons or dial another feature code.
ETR 18D/ETR 34D Phone
1. At either or the first two extensions on the system, press Feature 0 0 followed by two presses of the first
intercom or call appearance button.
2. System Administration: is shown on the display.
3. Dial #208. The phone displays Line Coverage Extension.
4. At the Line: prompt, enter the desired line number 01 to 64.
5. At the Extension: prompt enter the covering extension for the line.
·
Exit programming by pressing Feature 00. You can also exit programming mode by lifting the handset, then
placing it back in the cradle.
Phone Based Administration
IP Office Basic Edition
arrow buttons to scroll the display to System Administration. When highlighted, press
arrow buttons to scroll the display to Lines. When highlighted, press Select.
system administration
arrow buttons to scroll the display to Line Coverage Extension. When highlighted,
arrow buttons to select another line to adjust if required.
PHONE. Alternatively use the Back button to move to another menu.
system password set, it is requested. Enter the password.
