M7324/M7324N/M7310/M7310N/T7316/T7316E Phone
1. At either of the first two extensions on the system, press
·
If the system has a
2. The phone displays System Admin.
3. Dial #301. The phone displays Line Assignment.
4. At the Extension: prompt enter the extension you want to edit.
5. At the Line: prompt enter the line number. For systems running in PBX mode, the number of an ARS selector (65
to 99) can also be entered. The current setting is displayed.
6. The current setting is displayed.
·
1 = Assigned
The line is already assigned to a button on the extension. Changing the setting to not assigned will remove the
line from the line appearance.
·
2 = Not assigned
The line is not assigned to a button on the extension. Changing the setting to assigned will add the line to the
next button after lines already assigned to buttons on the extension.
7. Enter 1 or 2. If assigning a line, it is automatically assigned to the next non-line button after the intercom or call
appearance buttons.
8. To assign it to a particular button, press 3 and enter the button number of press the button required. This will
change any current button assignment of that line.
·
To exit phone based administration at any time, press the Release button. To select a different process use the
Next Procedure or Previous Procedure buttons or dial another feature code.
ETR 18D/ETR 34D Phone
1. At either or the first two extensions on the system, press Feature 0 0 followed by two presses of the first
intercom or call appearance button.
2. System Administration: is shown on the display.
3. Dial #301. The phone displays Line Assignment.
4. At the Extension: prompt enter the extension you want to edit.
5. At the Line: prompt enter the line number. For systems running in PBX mode, the number of an ARS selector (65
to 99) can also be entered. The current setting is displayed.
6. The current setting is displayed.
·
1 = Assigned
The line is already assigned to a button on the extension. Changing the setting to not assigned will remove the
line from the line appearance.
·
2 = Not assigned
The line is not assigned to a button on the extension. Changing the setting to assigned will add the line to the
next button after lines already assigned to buttons on the extension.
7. Enter 1 or 2. If assigning a line, it is automatically assigned to the next non-line button after the intercom or call
appearance buttons.
8. To assign the line to a particular button, press 3 and enter the button number of press the button required. This
will change any current button assignment of that line.
·
Exit programming by pressing Feature 00. You can also exit programming mode by lifting the handset, then
placing it back in the cradle.
Phone Based Administration
IP Office Basic Edition
system password set, it is requested. Enter the password.
114
Comments on this document? infodev@avaya.com
Feature **config (ie. Feature **266344).
