1.3.2 1408
This type of phone can be used for system, centralized and personal administration functions covered by this document.
For system and centralized administration, the phone must be connected to one of the first two extension ports on the
system.
The order of button numbering depends on the mode in which the system is running.
·
For systems running in key system mode, the programmable buttons are numbered from 01 upwards from left to
right, bottom to top. The first two buttons are fixed as intercom buttons Intercom 1 and Intercom 2.
·
For systems running in PBX system mode, the programmable buttons are numbered from 01 upwards from left to
right, top to bottom. The first three buttons are fixed as call appearance buttons.
Key System Mode
05
01
PBX System Mode
01
05
Phone Based Administration
IP Office Basic Edition
06 07
02 03
02 03
06 07
Comments on this document? infodev@avaya.com
08
04
04
08
Overview: DS Phones
