Avaya IP Office Basic Edition Manual page 156

M7324/M7324N/M7310/M7310N/T7316/T7316E Phone
1. At either of the first two extensions on the system, press
·
If the system has a
2. The phone displays System Admin.
3. Dial #311.
4. At the Extension: prompt, enter the extension.
5. The current setting is displayed.
6. Enter the external number and press Enter. Press Remove to remove any existing number. The following keys
can be used to enter special dialing commands:
Function Press to insert
Pause Soft Key 1
Transfer Soft Key 2
Stop Soft Key 3
·
To exit phone based administration at any time, press the Release button. To select a different process use the
Next Procedure or Previous Procedure buttons or dial another feature code.
ETR 18D/ETR 34D Phone
1. At either or the first two extensions on the system, press Feature 0 0 followed by two presses of the first
intercom or call appearance button.
2. System Administration: is shown on the display.
3. Dial #311. The phone displays External Hotline.
4. At the Extension: prompt, enter the external hotline extension number.
5. The current setting is displayed.
6. Enter the external number and press Enter. Press Clear to remove any existing number. The following keys can
be used to enter special dialing commands:
Function Press to insert
Pause HOLD
Transfer SPEAKER
Stop CONFERENCE
·
On 9500 Series phones, these options are accessed by pressing More and select Pause, Stop or Recall as
required.
·
Exit programming by pressing Feature 00. You can also exit programming mode by lifting the handset, then
placing it back in the cradle.
Phone Based Administration
IP Office Basic Edition
system password set, it is requested. Enter the password.
114
Character
P
R
S
Character
P
R
S
Comments on this document? infodev@avaya.com
Feature **config (ie. Feature **266344).
Description
Inserts a 1.5 second pause.
Send a hook-switch flash signal.
Stop dialing.
Description
Inserts a 1.5 second pause.
Send a hook-switch flash signal.
Stop dialing.
- Issue 6a (Thursday, February 22, 2018)
Page 156
