ETR 18D/ETR 34D Phone
1. At either or the first two extensions on the system, press Feature 0 0 followed by two presses of the first
intercom or call appearance button.
2. System Administration: is shown on the display.
3. Dial #124. The display will show System Manual Backup.
4. Press Enter 22 to start the backup. The display will show Backup in Progress.
5. If the backup was successful, the telephone display will show the message Backup Successful.
6. If a backup fails the telephone display will give the reason why the backup was unsuccessful.
·
Shutdown and Insert Card
No card was detected in the phone system's System SD card slot. For correct operation of the phone system
the Avaya SD card should always be present at all times.
·
System Busy
Another backup, restore, upgrade or copy was already in progress at the time the manual process was
requested.
·
Backup Failed
This message indicates that there was some problem. For example the card in the phone system's System SD
card slot was removed during the backup or the card has become corrupted.
·
Exit programming by pressing Feature 00. You can also exit programming mode by lifting the handset, then
placing it back in the cradle.
·
If you exit the procedure before the backup has finished, the backup will continue but no feedback will be
displayed.
