DWS-1008 User's Manual
Setting a TCP ACL
The following command filters TCP packets:
set security acl ip acl-name {permit [cos cos] | deny} tcp {source-ip-addr mask [operator
port [port2]] destination-ip-addr mask [operator port [port2]]} [precedence precedence] [tos
tos] [established] [before editbuffer-index | modify editbuffer-index] [hits]
For example, the following command permits packets sent from IP address 192.168.1.5 to
192.168.1.6 with the TCP destination port equal to 524, a precedence of 7, and a type of
service of 15, on an established TCP session, and counts the number of hits generated by
the ACE:
DWS-1008# set security acl ip acl-4 permit tcp 192.168.1.5 0.0.0.0 192.168.1.6 0.0.0.0
eq 524 precedence 7 tos 15 established hits
Setting a UDP ACL
The following command filters UDP packets:
set security acl ip acl-name {permit [cos cos] | deny} udp {source-ip-addr mask [operator
port [port2]] destination-ip-addr mask [operator port [port2]]} [precedence precedence] [tos
tos] [before editbuffer-index | modify editbuffer-index] [hits]
For example, the following command permits UDP packets sent from IP address 192.168.1.7
to IP address 192.168.1.8, with any UDP destination port less than 65,535. It puts this ACE
first in the ACL, and counts the number of hits generated by the ACE.
DWS-1008# set security acl ip acl-5 permit udp 192.168.1.7 0.0.0.0 192.168.1.8 0.0.0.0
lt 65535 precedence 7 tos 15 before 1 hits
Determining the ACE Order
The set security acl command creates a new entry in the edit buffer and appends the new
entry as a rule at the end of an ACL, unless you specify otherwise. The order of ACEs is
significant, because the earliest ACE takes precedence over later ACEs. To place the ACEs
in the correct order, use the parameters before editbuffer-index and modify editbuffer-index.
The first ACE is number 1.
To specify the order of the commands, use the following parameters:
• before editbuffer-index inserts an ACE before a specific location.
• modify editbuffer-index changes an existing ACE.
If the security ACL you specify when creating an ACE does not exist when you enter set
security acl ip, the specified ACL is created in the edit buffer. If the ACL exists but is not in
the edit buffer, the ACL reverts, or is rolled back, to the state when its last ACE was committed,
but it now includes the new ACE.
