4.4
Frame
System
4.4.1
Wheels
Put the machine in safe conditions.
Lift up the wheel from the ground.
Loose the screw that blocks the
wheel to the Drive Shaft
.
77)
Remove the wheel pulling it by
hands or using a extractor.
Proceed at reverse to refit the part
(Use the thread lock liquid on the
screw during the assembling).
4.4.1-77
4.4.2
Drive Shaft IMx BT
Put the machine in safe conditions.
Disassemble the wheel connected to
the axle in question
.
)
Remove the spacer
Remove the seeger
Remove the Drive Shaft from the
traction motor pulling it by hands or
using an extractor
Remove the bearings from the Drive
Shaft using an extractor
.
80)
Proceed at reverse to refit the part.
and
Traction
(see fig.
4.4.1-
(see section
at page
.
(see fig. 4.4.2-78)
.
(see fig. 4.4.2-79)
.
(see fig. 4.4.2-80)
(see fig.
4.4.2-
4.4.2-78
4.4.2-80
4.4.3
Traction Gearmotor IMx
BT
Put the machine in safe conditions.
Disassemble both wheels
.
at page
)
Disassemble both Drive Shafts from
the Machine
(see section
Unplug the Electrical connector of
the Traction Gearmotor
Loose the screws that block the
Traction Gearmotor to the Machine
Frame
(see fig. 4.4.3-82)
Remove the Traction Gearmotor
.
fig. 4.4.3-83)
Remove the Spacer from the Trac-
tion Gearmotor
Proceed at reverse to refit the part.
4.4.4
Free Shaft IMx B-BB
Put the machine in safe conditions.
Disassemble both wheels
.
at page
)
Disassemble the seeger
4.4.2-79
(see section
.
at page
)
(see fig. 4.4.3-81)
.
(see
.
(see fig. 4.4.3-83)
(see section
(see fig. 4.4.4-84)
4-37
.
