Slip off the motor carbon brushes
fig. 7.4.6-31)
7.4.6-31 Carbon brush re-
moval
Replace the worn
brushes with new ones.
Proceed at reverse to restore the
parts.
7.4.7
(see
Checks
The Drain Hose has to be perfectly fitted
in the recovery tank fittings. The Drain
Cap
the hose to avoid any pressure drop or
dirty water leakage. The Drain Flexible
Manifold
has to have no cracks to avoid any break
down during the bending to drain the
machine.
out carbon

Drain Hose

has to seal perfectly
(see fig. 7.4.7-32)
has to be flexible and
(see fig. )
7.4.7-32 Drain Hose
7-77
