4.2.6

Bumper Wheel

Release the Brush from the Brush
deck
(see fig. 4.2.2-29)
Put the machine in safe conditions.
4-30 Tilt the machine in the parking con-
ditions.
Loose the upper bushing of the
Bumper Wheel
Remove the Bumper Wheel.
Proceed at reverse to refit the part.
Note: Use the thread lock liquid on the
screw during the assembling.
4.2.6-42
(see fig. 4.2.6-42)
