Check / Monitor
Check / Monitor:
Show current of traction motor (IMx BT only)
I Tr: ### [Amp]
Check / Monitor:
Show current of brush motor .
I Br: ## [Amp]
Check / Monitor:
Show current of vacuum motor .
I Vac: ## [Amp]
Check / Monitor:
Show voltage of traction motor (IMx BT only).
V Tr: #### [V]
Check / Monitor:
Show battery voltage.
V Batt: #### [V]
Check / Monitor:
Show the voltage reference of the potentiometer (IMx BT only).
Vref: #.# [V]
Check / Monitor:
Show % speed of water pump.
Wtr Pump: ### [%]
Check / Monitor:
Show % speed of chemical pump.
Det Pump: ### [%]
Check / Monitor:
Show temperature inside of main card, related to brush/vacuum.
BR Temp: ## [C]
Check / Monitor:
Show temperature inside of main card, related to traction (IMx BT only).
TR Temp: ## [C]
Check / Monitor:
Show the percentage value of the amperometric protection of traction motor (when 100%
TR Ovrld: ### [%]
the amperometric protection cuts the current).
5-65
