4.3.5-54
4.3.6

Vacuum Hose

Put the machine in safe conditions.
Unplug the Vacuum Hose from the
Squeegee
(see fig. 7.4.3-21)
Uncouple the squeegee from the
plastic clip.
(see fig. 4.3.6-57)
Uncouple the Vacuum Hose from the
Recovery tank Inlet
Proceed at reverse to refit the part.
4.3.6-56
4.3.6-58
4.3.7
4.3.5-55
.
.
.
(see fig. 4.3.6-58)
Note:
Drain Hose.
4.3.6-57

Recovery Tank

Put the machine in safe conditions.
Uncouple the Vacuum Hose from the
Recovery tank Inlet
Unplug the Vacuum Manifold from
the Recovery Tank
(see fig. 4.3.7-60)
Uncouple the Drain Hose from the
clip and let it lie on the floor
.
4.3.7-61)
Remove the cap from the Recovery
tank .
(see fig. 7.4.4-22)
Remove the Recovery tank from the
machine by lifting up it using the
handles. Be careful to slip off the
Drain hoses without damaging it
.
fig. 4.3.7-63)
Put the Recovery Tank vertically on
the floor.
Proceed at reverse to refit the part.
Be careful to not damage the
.
(see fig. 7.4.3-20)
.
(see fig.
(see
4-33
