5.13

Alarm Table (IMx B/BT only)

5.13.1 Alarms

Alarms of Overcurrent and Temperature

Id Alarm Meaning
AL 1: Function Brush Amperometric Protection
Amp. Brush
AL 2: Function Vacuum Amperometric Protec-
Amp. Vacuum tion
AL 3: Function Damage of Power
Power Broken
AL 4: Function Output overcurrent on brush or
Overcurrent vacuum
AL 5: Function Thermal
Overtemperature brush/vacuum

Traction Alarms

Id Alarm Meaning
AL 14: Traction Safety lever pressed before start-
Lever pressed ing
AL 15: Traction Thermal protection on traction
Overtemperature
AL 16: Traction Power of traction damage
Power damage
AL 17: Traction Traction Overcurrent
Overcurrent
AL 18: Traction Traction Amperometric protec-
Amp. Traction tion

General Alarms

Id Alarm Meaning
AL 20: General Error reading internal memory
EEprom malfunction
AL 21: General Error key sequence
Key
AL 22: General Damage of general relay
General Relay
AL 23: General Overvoltage
Overvoltage
AL 24: Traction Battery not connected to the
Battery connections main card
AL 25: General No communication between con-
Control Card connec- trol card and main card
tion
Solution
Check consumption of the brush motor. Detected high current
on brush motor.
Check consumption of the vacuum motor. Detected high cur-
rent on vacuum motor.
Damage power of brush or vacuum: replace the main card.
This alarm could be shown also during the trailing of the ma-
chine.
Detect a shortcircuit on output brush motor or vacuum motor:
Check connections and motors.
protection on Overtemperature of brush/vacuum motor: check consump-
tion of motors.
Solution
Detected safety microswitch pressed before starting : release
the safety lever.
Overtemperature on traction : check consumption of traction
motor (IMx BT).
Replace the main card. This alarm could be shown also during
the trailing of the machine. (IMx BT)
Detected a shortcircuit on the traction motor output: Check
connections and traction motor (IMx BT).
Check how the traction function is used. Detected too high
working current on traction motor (IMx BT).
Solution
Replace the main card.
Error on key signal: Check the key connection. Check, also,
the batteries connections and main card
Check the traction motor connections. If the connection are
OK, the general relay on the main card is damaged: replace
the main card. The same alarm is present also if power fuse is
damaged
Detected a overvoltage on the main card. Check the batteries
connections.
Check the traction motor, Detected high voltage on traction
motor (IMx BT)
Check the connections between control card and main card.
5-59
