5.8 Hourmeter (IMx BB
only)
The machine is equipped with an elec-
tronic hourmeter, installed on the dash-
board. The hourmeter shows the battery
charge level by its leds. The hourmeter
can stop the machine if the charge of the
batteries is under a minimum threshold.
On the hourmeter is possible to set up a
different type of batteries.
5.9

Charger

The charger is available as optional. The
charger is located on the left rear part of
the machine, with free access to connect
the charger to the power supply.
5.10

Batteries

On the machine is possible to install two
different type of batteries: 12V 77Ah and
12V 62Ah (2 batteries for each type on
the machine). Depending of the batter-
ies installed, is necessary to change the
position of the batteries metal supports
on the battery base.
Batteries 12V 77Ah
Batteries 12V 62Ah
5-55
