Charging curve SetUp

To set up the charger, follow the instruc-
tions:
Use a screwdriver to remove the
small black plastic cap
Set-up the internal dipswitches ac-
cording to the following table
The dipswitches are divided in two cou-
ple. The higher couple are the dip-
switches 1 and 2, the couple down are
the dipswitches 3 and 4.
ing table shows how to setup the dip-
switches 1 and 2
Set-up of Charging Curve
DP1 DP2 Set-up
OFF OFF Wet cell batteries
ON ON Gel TROJAN
OFF ON Generic
AGM batteries
ON OFF Gel EXIDE SON-
NENSCHEIN
DP3: OFF (not used)
DP4: OFF (not used)
Restore the the small black plastic cup.
The follow-
Flash
1
2
GEL or 3
4

Error Codes of Charger

The charger have an alarm system. The
alarm code is shown by blinks of the yel-
low led.
Error code
Flash Description
1 Wrong battery, Inverted polarity,
short circuit to the exit
2 Timeout alarm, Defect of the bat-
tery
3 Defect of the Charger
4 Overtemperature alarm
5.11.3 ECO Function (solo IMx
B/BT)
Press the ECO button, and let the vac-
uum motor and the brush motor work.
with the ECO mode activated, check if
the noise of the vacuum motor and the
brush motor is reduced.
Amperometric to the positive cable of the
batteries and check if the current con-
sumption is less than normal function
(without ECO mode). ATTENTION. We
don't give the amperometric values be-
cause it can change depending of the
working conditions.
5-57
Connect an
