3.2

Frame and traction system: what to do if. . .

3-16
(Only BT) The traction motor doesn't work properly
1) The machine is switched off
2) The machine doesn't switch on
3) The display shows an error mes-
sage
4) The dead man lever is not pressed
5) The dead man switch is not prop-
erly connected
6) The dead man switch doesn't work
7) The speed adjuster is at its mini-
mum
8) The motor is not supplied
9) The traction motor is supplied but
it doesn't work
1) (Only BT) The parking brake is en-
gaged
2) The brush is not properly engaged
3) The brush deck is not properly ad-
justed
The machine doesn't move straight
Switch on the machine.
Check the proper section
.
at page 8)
Check the proper section.
Push the dead man lever.
Restore the proper connection to the
dead man switch.
Replace the dead man switch.
Rotate the speed adjuster to in-
crease the speed.
Verify the motor connections.
Replace the traction motor.
Release the brake.
Release the brush and engage it
properly.
Adjust properly the brush deck.
(see section 3.1
