4.3

Drying System

4.3.1

Squeegee

Put the machine in safe conditions.
Lower the Squeegee in working con-
ditions.
Unplug the Vacuum Hose
.
43)
Loose the knobs that block the
Squeegee to the Squeegee Support
.
(see fig. 4.3.1-43)
Remove the Squeegee from the

Squeegee Support

Proceed at reverse to refit the part.
Perform the adjustment procedure
for the Squeegee
Note: The Squeegee has to be refit on the
machine with the washers on the upper
part of the Squeegee Support
.
45)
4.3.1-43
4.3.1-45
(see fig. 4.3.1-
.
(see fig. 4.3.1-44)
.
(see section 7.3.1 at page 68)
(see fig. 4.3.1-
4.3.1-44
4.3.2

Squeegee Adapter

Put the machine in safe conditions.
Disassemble the Squeegee from the
Machine
(see section
Loose the knobs that block the
Squeegee to the Squeegee Support
.
(see fig. 4.3.2-46)
Remove the Squeegee Adapter.
Proceed at reverse to refit the part.
4.3.2-46
4.3.3 Squeegee Support
Put the machine in safe conditions.
Disassemble the Squeegee from the
Machine
(see section
Be sure that the Squeegee Com-
mand Lever is in lower position.
Unscrew the screw that fix the chain
to the Squeegee Command Lever and
let it lie behind the Squeegee Sup-
port
(see fig. 4.3.12-75)
Loose the nuts that block the Gas
Spring to the Squeegee Support and
Remove the Gas Spring
Loose the screws that block the
Squeegee Support to the Squeegee
Rotation Arm
(see fig. 4.3.3-50)
Remove the Squeegee Support
.
4.3.3-51)
.
4.3.1 at page 26)
.
4.3.1 at page 26)
.
.
(see fig. 4.3.3-49)
.
(see fig.
