6.5

Technical Features

TECHNICAL DESCRIPTION
Working width
Working capacity, up to
Number of brushes
Maximum diameter of the active part of the brush
Brush turns
Brush motor voltage
Brush motor power
Max weight on brush
6.6 Consumable Spare Parts
PN Bristle type
404654 PPL
405631 PPL
404653 PPL
405632 ABRASIVE
405527 -
422462 -
6.7 Recommended Spare parts
PN
223301
436120
437859
438300
Bristle (mm) Bristle colour
0.3 Blue
0.6 White
0.9 Black
0.9 -
- -
Carbon Brushes
- -
Description
GEAR MOTOR 24V 500W 140RPM H2O W/MOLEX
BASE BUMPER WHEEL D=100 H=20
BRUSH FLANGE
GEAR MOTOR 24V 500W 140RPM THREADED SHAFT.
U/M IMx BB IMx B
mm 508 508
m2/h 2032 2032
Nr 1 1
mm 508 508
rpm 166 166
V 24 24
W 500 500
kg 25 25
Brush (mm) Description
508 BRUSH PPL 0.3
508 BRUSH PPL 0.6
508 BRUSH PPL 0.9
560 BRUSH TYNEX
500 PAD HOLDER
- BRUSH MOTOR CARBON BRUSHES
IMx BT
508
2032
1
508
166
24
500
25
iMx
BB B BT
6-71
