Technical Features; Recommended Spare Parts - Fimap IMx Workshop Manual

5.15

Technical Features

TECHNICAL DESCRIPTION
Dimension of Battery compartment (l x L x h)
Batteries Rated Voltage
Maximum batteries weight (battery 12V 77Ah)
5.16

Recommended Spare Parts

5-66
PN Description
412123 HOSE FASTENING SPRING D=38 ABS
437657 CHARGER NE286 24V 11A
210516 COMPLETE KEY SWITCH (ELFI D.22)
436267 CONTROL CARD
438057 MAIN CARD IMX COD.7CFS0000
438158 POTENTIOMETER
407578 DOUBLE REMOTE CONTR SW. 24V 100A SW84-P
407580 RELAY FINDER 65.31 30 A, 24 V SUCT. MOT.
409607 FUSE 30A
409612 FUSE 50A
426356 ELECTRONIC HOURMETER D=51,5 L=49
438351 SWITCH BLACK 16A FASTON 6.3
438352 SWITCH 16A FASTON 6.3
434431 SWITCH ON-MOM 645H/2 10A 250V
U/M IMx BB IMx B IMx BT
mm 353x333x250
V
2x(12/77)
Ah
kg 2x26,5
iMx
BB B BT
