Wheels; Checks; Maintenance; Adjustments - Fimap IMx Workshop Manual

8.3

Adjustments

8.3.1 Parking Brake Lever (IMx
BT only)
The lever
justed to ensure the proper arrest of the
machine once it is fully pressed on the
drive wheel.
8-80
Procedure
Secure the machine.
Unscrew the adjusting nut, so as
to appropriately increase or decrease
the run of the buffer.
Check the correct operation of the
parking brake.
Lock the adjusting nut.
have to be ad-
(see fig. 8.3.1-33)
8.3.1-33 Parking Brake
Lever
8.4

Maintenance

Checks

8.4.1

Wheels

Checks
The wheel must be free to rotate
smoothly without friction.
surface, must always be in good condi-
tion.
Maintenance
Periodically check the condition of the
bearings and bushings of the wheels. If
necessary, replace the part
.
at page 32)
8.4.2 Traction Motor (Only IMx
BT model)
Checks
During normal driving, the power con-
sumption must be between 3 and 5
Amps.
ATTENTION: At the start, the power
consumption of the motor is much
higher.
The carbon brushes of the traction mo-
tor must be at least 6-8 mm long. The
insulation of the motor supply cables
should be complete in every part and
show no signs of cracks.
must be flexible. When lifting the ma-
chine to put the front wheels in neutral
by spinning a wheel (in any sense) the
other must turn in the opposite direc-
tion.
and
The wheel
(see section 4.4.1
The cables
