Drain Hose; Vacuum Filter; 10Vacuum Motor - Fimap IMx Workshop Manual

4-34
4.3.7-59
4.3.7-61
4.3.8

Drain Hose

Put the machine in safe conditions.
Remove the Recovery Tank
4.3.7 at page 28)
Loose the clamp that block the Drain
Hose to the Recovery Tank
.
64)
Unplug the Drain Hose from the Re-
covery Tank.
Proceed at reverse to refit the part.
4.3.7-60
4.3.7-62
4.3.7-63
(see section
(see fig.
4.3.8-64
4.3.9

Vacuum Filter

Put the machine in safe conditions.
Remove the Recovery Tank Lid
.
4.3.9-65)
Uncouple the Filter Cover.
66)
Remove the Vacuum Filter pulling it
down
(see fig. 4.3.9-67)
Proceed at reverse to refit the part.
4.3.9-65
4.3.8-
4.3.10 Vacuum Motor
Put the machine in safe conditions.
Remove the Recovery Tank
4.3.7 at page 28)
Remove the clamp that block the
Vacuum Manifold to the Vacuum
Motor and move it apart
.
68)
Loose the screws and remove the
Vacuum Motor Cover
Remove the Upper sound-absorbing
Sponges.
(see fig.
(see fig.
.
4.3.9-66
4.3.9-67
(see section
(see fig. 4.3.10-
(see fig. 4.3.10-69)
4.3.9-
.
