4.5 Solution Delivery Sys-
tem
4.5.1

Solution Tank

Put the machine in safe conditions.
4-40
Remove the recovery tank.
4.3.7 at page 28)
Disconnect the water supply hose
from the solenoid valve.
Loosen the screws securing the so-
lution tank to the scrubdeck
4.5.1-88) (see fig. 4.5.1-89)
Remove the solution tank from the
machine frame
Loosen the screws of the battery
compartment and remove it from the
tank
(see fig. 4.5.1-91)
Remove the Support plate unscrew-
ing the fixing screws.
Remove the brush/squeegee holder,
by unscrewing the fixing screws
fig. 4.5.1-93)
Remove the object holder and un-
screw the screw on the magnet.
fig. 4.5.1-94)
Remove the solution filter
4.5.3 at page 36)
Remove the water control Valve
Group
Remove the hose connector and its
fastening clamp
Remove the parking brake (ONLY BT
VERSION)
Remove the vacuum motor
4.3.10 at page 29)
Remove the vacuum motor lower
carter.
Proceed at reverse to refit the part.
.
(see fig. 4.5.1-90)
.
(see fig. 4.5.1-92)
(see section 4.5.4 at page 36)
(see fig. 4.5.1-95)
(see section 4.4.6 at page 34)
4.5.1-88
(see section
(see fig.
4.5.1-90
.
4.5.1-92
(see
4.5.1-94
(see
(see section
.
(see section
4.5.1-89
4.5.1-91
4.5.1-93
4.5.1-95
