Chapter 3
Trouble-shooting for the most common
anomalies.
3.1

Electrical system: what to do if. . .

1) (Only B-BT) The key is in position 0
2) (Only BB) The main switch is in po-
sition 0
3) (Only B-BT) The key switch is not
properly connected
4) (Only BB) The main switch is not
properly connected
5) (Only B-BT) The key switch doesn't
work
6) (Only BB) The main switch doesn't
work
7) The machine is not powered prop-
erly
The machine doesn't switch on
13
Rotate the key in position I.
Push the switch in position I or II.
Restore the proper connections.
Restore the proper connections.
Replace the key switch
.
at page 19)
Replace the main switch
.
4.1.10 at page 20)
Refer to the proper section
.
3.1 at page 9)
3-13
(see section 4.1.8
(see section
(see section
