1) The batteries are not properly con-
nected
3-14
2) Battery are discharged
3) Battery terminal are oxidized
4) With the machine in working con-
ditions one battery has a voltage
lower (difference higher than 2 V)
than the other ones
5) The fuse on the loop wire is dam-
aged
6) The power wires are damaged
7) The battery charger is not properly
adjusted
8) The battery charger doesn't work
1) The battery charger is not con-
nected to the power supply
2) The battery charger is not con-
nected to the batteries
3) The battery charger has one or
more lights (or LEDs) blinking con-
tinuously
4) The battery charger is properly con-
nected but it doesn't switch on
The batteries don't work properly
The battery charger doesn't work
Restore the proper battery connec-
tions.
Perform a complete charge cycle.
Disconnect the batteries, clean the
batteries terminals and reconnect
properly the batteries.
Replace the battery with lower volt-
age.
Check for possible short circuits, If
not present replace the loop wire.
Replace the damaged wires.
Adjust properly the battery charger.
Check the proper section
.
at page 9)
Connect the charger to a supplied
electric socket.
Connect the charger to the batteries.
The battery charger is in error con-
ditions, verify the alarm tables and
solve the issue by following the re-
lated instructions
(see section
Replace the battery charger.
(see section 3.1
.
5.9 at page 50)
