3.4

Frame and traction system: what to do if. . .

The traction motor doesn't work properly
1 The machine is switched off
2 The machine doesn't switch on
3 The batteries are discharged
4 The operator is not sitting on the
seat
5 The operator is sitting on the seat
6 The pedal is not pressed
7 The pedal is pressed
8 The display shows an alarm mes-
sage
9 The brush deck motor is not sup-
plied
10 The electrobrake doesn't disengage
Switch on the machine.
Check the proper section
.
at page 9)
Connect the battery charger and
perform a complete charge cycle.
The operator must sit on the seat.
Check and / or replace the deadman
seat microswitch.
Press the pedal depending on the re-
quired speed.
Check and / or replace the poten-
tiometer or the microswitch inside
the pedal.
Check what alarm message is
shown and solve the related issue
by following the proper instructions
.
(see section 5.6.1 at page 44)
Verify the motor connections.
Check the connections of the electro-
brake.
3-15
(see section 3.1
