Loose the screws that block the
Brush Motor Contactor to the Elec-
tric Panel
Remove the Brush Motor Contac-
tor
(see fig. 4.1.12-20)
4-26
Proceed at reverse to refit the part.
4.1.12-20
4.1.13 Brush
IMx BB
Put the machine in safe conditions.
Remove the Function Dashboard
section 4.1.2
Remove the Rear Dashboard
4.1.6 at page 18)
Loose the Rubber Cap that protect
the Brush Release Switch (Rif. SBR)
(see fig.
Loose the nut that blocks the Brush
Release Switch to the Rear Dash-
board
Remove the Brush Release Switch
from the Rear Dashboard.
Proceed at reverse to refit the part.
.
(see fig. 4.1.11-19)
.
Release
at page 17)
.
)
.
(see fig. 4.1.13-21)
4.1.13-21
4.1.14
Put the machine in safe conditions.
Loose the screws and remove the
handle
Unplug the bipolar connector that
connects the Dead Man Switch to
the Electrical installation of the ma-
chine (it's on the right hand side of
the handle).
Remove the screws that secure the
Switch
microswitch support to the handle-
bar
(see fig. 4.1.14-24) (see fig. 4.1.14-25)
Remove the Dead Man Switch.
(see Proceed at reverse to refit the part.
(see section
4.1.14-22
4.1.14-24
Dead Man Switch
(see fig. 4.1.14-22) (see fig. 4.1.14-23)
4.1.14-23
4.1.14-25
.
.
