3.3

Drying system: what to do if. . .

1 The machine is switched off
2 The machine doesn't switch on
3 The squeegee is lifted up from the
floor
4 The squeegee rubber blades are
worn out or broken
5 The recovery tank is full
6 The squeegee is not properly ad-
justed
7 The squeegee vacuum chamber is
stuck or dirty
8 The squeegee adapter is stuck or
dirty
9 The vacuum hose is stuck or bro-
ken
10 The vacuum hose is not properly
fitted in
11 The vacuum filter is dirty or stuck
12 The vacuum cover is not well posi-
tioned or is missing
13 The vacuum cover gasket doesn't
adhere properly
The machine doesn't dry well
Switch on the machine.
Refer to the proper section
.
3.1 at page 9)
Lower down the squeegee.
Rotate or replace the squeegee rub-
ber blades.
Empty the recovery tank following
the proper procedure.
Adjust the squeegee properly follow-
ing the proper procedure
.
at page 58)
Clean the squeegee vacuum cham-
ber.
Clean the squeegee adapter.
Clean or replace the vacuum hose.
Connect the vacuum hose properly.
Disassemble and clean the vacuum
filter.
Position properly the vacuum cover.
Replace the vacuum cover gasket.
3-13
(see section
(see section 7.3.1
