ENGINEER
PROGRAMMING
MANUAL
ECLIPSE 8
ECLIPSE 16
ECLIPSE 32
(S.W. 1.9x)
ALARM CONTROL PANELS
Attention:
This manual contains information on limitations regarding product use and
function and information on the limitations as to liability of the manufacturer.
The entire manual should be carefully read.
The information in this manual is a subject to change without notice!

Advertisement

Table of Contents
loading

Related Manuals for Teletek electronics ECLIPSE 16

Summary of Contents for Teletek electronics ECLIPSE 16

  • Page 1 ENGINEER PROGRAMMING MANUAL ECLIPSE 8 ECLIPSE 16 ECLIPSE 32 (S.W. 1.9x) ALARM CONTROL PANELS Attention: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read.

  • Page 2: Table Of Contents

    Eclipse 8/ 16/ 32 Series - Engineer Programming Manual Table of Contents: 1. GENERAL INFORMATION ............................... 4 2. SUPPORTED KEYBOARDS FOR PROGRAMMING AND OPERATION ................7 2.1. LED/LCD Keyboards ............................... 7 2.2 Sound Signalization from the Keyboards ......................... 8 2.3. Supported Trouble Events in ECLIPSE Series ........................ 8 2.4.
  • Page 3 The manufacturer shall not accept any product, of which no prior notice has been received via the RAN form at: http://www.teletek- electronics.com/en/support/Service The setup and programming included in the technical documentation shall not be regarded as defects. Teletek Electronics bears no responsibility for the loss of programming information in the device being serviced. CONDITIONS FOR WAIVING THE GUARANTEE This guarantee shall apply to defects in products resulting only from improper materials or workmanship, related to its normal use.

  • Page 4: General Information

     ECLIPSE 8 for management of small sites up to 8 zones organized in 1 common area.  ECLIPSE 16 for management of small to medium sites up to 16 zones organized in 3 independent areas.  ECLIPSE 32 for management of medium sites up to 32 zones and 8 independent areas.
  • Page 5 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual  3-digit operations. The programming of the system parameters is organized with 3-digit operation codes. The menus have the following structure: 0хх – General Settings Menu. 1xx – General User Menu; 1uu - Options for Users, as “uu” is an option number; after the option number is necessary to enter a user number from 01 to 64.
  • Page 6 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual There are several ways for setting parameters – that depends on the menu: - When the submenu allows choosing only one option or attribute, or parameter from a list, the installer button.

  • Page 7: Supported Keyboards For Programming And Operation

    Eclipse 8/ 16/ 32 Series - Engineer Programming Manual 2. SUPPORTED KEYBOARDS FOR PROGRAMMING AND OPERATION Eclipse 8/16/32 alarm control panel supports operation with the full range of Eclipse Series keyboards. ATTENTION: The operation with text menus is set by default for control panels ECLIPSE 8/16/32. The text menus are accessible for operation with LCD keyboards.

  • Page 8: Sound Signalization From The Keyboards

    Eclipse 8/ 16/ 32 Series - Engineer Programming Manual Summary for ECLIPSE Series Keyboards: Keyboard Display Areas Zones Proxi Address Operation Text menu AUX PGM      LED 8      LED 16  ...

  • Page 9: Buttons Functions

    Eclipse 8/ 16/ 32 Series - Engineer Programming Manual 2.4. Buttons Functions Note: The functionality of BYPASS, TROUBLE and MEMORY buttons for LED8 and LED16 (A) keyboards is accessible through the manager and user menus only with the respective LED indication on the display. The specialized LED indication of the LED8/ 16A keyboard is described in details in item 2.5.

  • Page 10: General Information For Operation With Led8/ 16A

    Eclipse 8/ 16/ 32 Series - Engineer Programming Manual 2.5. General Information for Operation with LED8/ 16A LED8/ 16A are a compact size keyboards with LED display, suitable for management and programming of ECLIPSE Series control panels. The keyboards have indication for 8/ 16 zones and can control one 1/ 3 area. LED8/ 16A are equipped with specialized LED indication for informing the installer of the set programming style menu and specific visualization of the programming values and parameters.
  • Page 11 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual from 1 to 3 are lighting on, the zone 1 is blinking, and lighting on button shows the first digit of the address (operation) number. 3. Press the right arrow button. The cursor will move one position on the right, zone 2 starts blinking and lighting on digit number shows the next number of the address (or operation).

  • Page 12: General Information For Operation With Led16 And Led32

    The keyboards LED 16(A) and LED 32 operate with limited functionality when connected to ECLIPSE 8 control panel – operation with one area (A in LED16) and 8 zones. LED 32 operate with limited functionality when connected to ECLIPSE 16 control panel – operation with three areas (A, B and C) and 16 zones. - Engineer Programming The engineer programming menus are accessible only when the system is disarmed.

  • Page 13: General Information For Operation With Lcd Keyboard

    Eclipse 8/ 16/ 32 Series - Engineer Programming Manual - Manager Programming To access the manager programming menus enter valid manager code (0000 by default). A confirmation sound signal will be heard. Press the PRG ( ) button to enter in manager programming menus. Zone numbers 15 and 16 are lighting on, and both LEDs “Lightning”...

  • Page 14: Programming With Specialized Proste Software

    Eclipse 8/ 16/ 32 Series - Engineer Programming Manual Table of the symbols and codes correspondence: Example: To enter the „asterisk” symbol, first press the MEMORY button (a solid cursor appears on the place) and after that enter code 042. The asterisk symbol will appear and the cursor will move one position to the right.

  • Page 15: Operation With A Service Keyboard

    Eclipse 8/ 16/ 32 Series - Engineer Programming Manual 4. OPERATION WITH A SERVICE KEYBOARD The service keyboard is a device, which is not a part of the system configuration, but can provide full access to all engineer programming menus. Every keyboard of Eclipse Series can be used as service, when it is not enrolled at address in the system configuration.

  • Page 16: Enrolling Devices To A Working System Configuration Via Lcd Keyboard

    1 proximity card reader. ** Eclipse 16: Up to 5 devices can be enrolled to the system bus irrespective of their type. *** Eclipse 32: Up to 31 devices can be enrolled to the system bus irrespective of their type.

  • Page 17: Enrolling Devices To A Working System Configuration Via Led Keyboard

    1 proximity card reader. ** Eclipse 16: Up to 5 devices can be enrolled to the system bus irrespective of their type. *** Eclipse 32: Up to 31 devices can be enrolled to the system bus irrespective of their type.

  • Page 18: Organization Of The Engineer Programming Menus

    Eclipse 8/ 16/ 32 Series - Engineer Programming Manual The access to the Engineer programming menus is from one keyboard only while all other connected to the system bus keyboards are temporally disabled for any operation. The LCD keyboards display a message „Engineer Mode!!!” The default programming style is the one using text tree-structure for the engineer menus.

  • Page 19: Special Symbols

    - The option, parameter or setting is available or specific for ECLIPSE 8 control panel. - The option, parameter or setting is available or specific for ECLIPSE 16 control panel. - The option, parameter or setting is available or specific for ECLIPSE 32 control panel.

  • Page 20: Engineer Menus - Programming Tables

    “0”. The keyboard will confirm the operation with a sound signal and will wait for entering of a new 4/6*-digit button (see also the description of address 1000). The new code is confirmed with ENTER button. * ECLIPSE 8/ ECLIPSE 16 allows operation only with 4-digit access codes. Engineer Code by Default: 7777 ADDRESS...
  • Page 21 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 0010 AMBUSH OPERATION CODE TEXT MENU 2. SETTINGS – 01. AMBUSH CODE At this address, you set the parameter as: DISABLE Ambush code is not supported - the parameter is deactivated. ENABLE Ambush code is supported - the parameter is active.
  • Page 22 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 0012 CHIME OPERATION TEXT MENU 2. SETTINGS – 02. CHIME Chime Sound Signalization At this address, you set the parameter as: The “Chime” sound signalization is deactivated. DISABLE The “Chime” sound signalization is activated. ENABLE At this address, the engineer can enable or disable the “Chime”...
  • Page 23 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 0014 CONF. OPERATION TIMER TEXT MENU 2. SETTINGS – 04. CONF. TIMER “Confidential Mode” Timer This parameter is common for all keyboards. Enter a time from 10 to 180 seconds. The “Confidential mode”...
  • Page 24 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 0017 ALARM OPERATION DELAY TEXT MENU 2. SETTINGS – 07.ALARM DELAY Programming of alarm message delay to monitoring station and siren activation with 30 seconds or until the programmed entry time is over (the smaller value of both times is taken) in case a zone, out of the entry route, is activated.
  • Page 25 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 0023 COMM TEST OPERATION TEXT MENU 1. MAINTENANCE – 4. COMM TEST The performance of the communicator can be directly monitored at this address. Before starting the monitoring of the communicator performance, you have to enter a telephone number at ADDRESS 6010.
  • Page 26 Review of memory LOG events in the system. The memory LOG file is with different capacity: 256 (ECLIPSE 8) and 1024 (ECLIPSE 16/ 32) system events. The events recorded in the power independent memory of the control panel can be traced with the help of the arrows.
  • Page 27 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 0051 TIME OPERATION TEXT MENU 2. SETTINGS – 12. TIME Setting the built-in clock The engineer sets at this address the current time (HH:MM). Default setting: [00:00] ADDRESS 0052 DATE OPERATION TEXT MENU 2.

  • Page 28: Users

    ECLIPSE Control Panels Series – User capability: Control panel Max. user codes Code digits Chief Manager Max. Manager codes ECLIPSE 8 ECLIPSE 16 ECLIPSE 32 Up to 64 Quick table for 1. Users Programming Menu Address Number Programming parameter ECLIPSE 8 ECLIPSE 16 ECLIPSE 32 ...
  • Page 29 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 1000 CODE OPERATION LENGTH TEXT MENU 3. CODES – 3. CODE LENGTH Code digits length The system allows using 4 and 6 digits codes: engineer, maintenance and users. Every pressing of a digital button or the arrows alternatively changes the digits number. The set parameter is confirmed with ENTER button.
  • Page 30 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 1010 U1 OPTIONS OPERATION 110+01 TEXT MENU 3. CODES – 1. USERS – 01. USER – 1. OPTIONS User 01 Operation rights User code 01 is the Chief Manager in the system and always has full rights for operation and programming of the system, which cannot be changed or erased! The following options are available for User Code 01: 1.
  • Page 31 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 1012 U1 NAME OPERATION 112+01 TEXT MENU 3. CODES – 1. USERS – 01. USER – 3. NAME Programming of the User 01 Name The engineer can enter a new name for User 01 at this address. The name has to be up 16 symbols –...
  • Page 32 To disable/ enable all user operation rights press button “0” – the button alternatively switches over all enabled / all disabled state. Default settings: User codes ECLIPSE 8 ECLIPSE 16 ECLIPSE 32 1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4, 8...

  • Page 33: Zones

    ECLIPSE Control Panels Series – Zones capability: Control panel Max. Zone Connection styles Doubling zones  ECLIPSE 8  ECLIPSE 16  ECLIPSE 32 Quick table for 2. Zones Programming Menu Address Number Programming parameter ECLIPSE 8 ECLIPSE 16 ECLIPSE 32 ...
  • Page 34 Choose a number from according the realized zone connection. ECLIPSE 8 supports only single connection in the zones. ECLIPSE 16 supports only single connection in the zones. ECLIPSE 32 supports both single and doubling connection in the zones.
  • Page 35 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 2001 Z ABYPASS OPERATION TEXT MENU 4. INPUTS – 2. AUTO BYPASS Number of Activations per Zone for Auto Bypass Mode The number of activations (number of alarm cycles from 1 to 9) in one arm mode, which have to be accomplished for a zone with an assigned AUTOBYPASS parameter, are entered at this address.
  • Page 36 The installer can review the device number and its input/ output number associated to the zone. In the maximal configuration of ECLIPSE 16 can be attached and programmed up to 16 zone numbers. In the maximal configuration of ECLIPSE 32 can be attached and programmed up to 32 zone numbers –...
  • Page 37 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual Example 1. At address 8020 (Device 02) to the control panel is enrolled a keyboard with one on board zone input. Choose a free zone in the system configuration, number 15 for example, where to attach the keyboard zone.
  • Page 38 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual address 8xx2 – keyboard options). Instant zone. An alarm zone which is active only when the site is armed. The zone operates instantaneously and activates the programmable ALARM and SIREN type outputs, and the communicator. INSTANT When the system is disarmed, the activation of the zone is indicated with active zone number for the time that the zone remains open.
  • Page 39 When this zone type is assigned, respectively a number of AUX attribute AUXILIARY should be programmed at ADDRESS 2xx7, where xx is the number of the zone (OPERATION 217 + xx). Default setting: Type Zone number ECLIPSE 8 ECLIPSE 16 ECLIPSE 32  09-16   17-32 ADDRESS...
  • Page 40 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual Attribute Description Authorization for automatic Bypassing the zone after reaching the number Auto BYPASS of activations per armed mode as set at address 2001 (OPERATION 201) for an arming mode. Authorization to Bypass a zone. Assigning this attribute to the respective BYPASS zone will authorize bypass of the zone on behalf of the system user or manager.
  • Page 41 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual The siren and outputs siren type will be activated but the communicator starts Fire waiting for 30 up to 90 seconds according the fire delay operation algorithm – refer Delay to the algorithm diagram in APPENDIX 3. Silent alarm.
  • Page 42 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 2016 OPERATION 216 + 01 KSWITCH TEXT MENU 4. INPUTS – 5. ZONES – 01. ZONE – 6. KEY SWITCH Setting of Key-Switch Attributes for Zone 01 At this address are assigned only attributes for Key-Switch type zone. More than one attribute can be assigned for the zone.
  • Page 43 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 2017 Z1 AUX OPERATION 217 + 01 TEXT MENU 4. INPUTS – 5. ZONES – 01. ZONE – 7. AUXILIARY Setting of Auxiliary Attributes for Zone 01 At this address are assigned only attributes for Auxiliary type zone. Only one attribute AUX can be assigned at this address - a number from 0 to 9.
  • Page 44 The both zones are open. See also APPENDIX 6. The ZONES with numbers from 02 to 08 for ECLIPSE 8, from 02 to 16 for ECLIPSE 16 and from 02 to 32 for ECLIPSE 32 are programmed in an analogical way.

  • Page 45: Pgm Outputs

    ECLIPSE Control Panels Series – PGM capability: Control panel Max. PGM outputs Power output, up to 1A ECLIPSE 8 1 (PGM 5), non-monitored ECLIPSE 16 1 (PGM 5), non-monitored ECLIPSE 32 1 (PGM 5), monitored Quick table for 3. PGM Outputs Programming Menu Address Number...
  • Page 46 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 3000 OPERATION OPTION TEXT MENU 5. OUTPUTS – 1. PGM OPTION Programming the type of PGM 04 The PGM 04 can be configured with different functionality for the ECLIPSE panels at this address. See the descriptions below to orientate in the available option settings.
  • Page 47 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual appropriate for connecting of control or signal devices. The keyboard PGM takes all common setting for PGM outputs. To add a keyboard PGM output to the system configuration it must be first attached to a PGM address and device –...
  • Page 48 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual This option concerns the set value at ADDRESS 3019 – time delay for DELAY sec / min* activation of PGM 01: – the set time delay at address 3019 is measured DELAY seconds () in seconds.
  • Page 49 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 3012 PGM 01 OPERATION 312 + 01 AREAS TEXT MENU 5. OUTPUTS – 2. PGMs – 01. PGM – 3. AREAS Association of Areas to PGM 01 According the system configuration the engineer associates one or several AREA numbers for operation with PGM 01.
  • Page 50 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 3017 PGM 01 OPERATION 317 + 01 DEACT. TM TEXT MENU 5. OUTPUTS – 2. PGMs – 01. PGM – 7. DEACT TIMER Deactivation timer for PGM 01 – setting a time for deactivation the event programmed at address 3013 A deactivation timer for the programmed at ADDRESS 3013 event is set at this address.
  • Page 51 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual Alarm cycle Activated on “OR” function (if at least one of Enter zone number “TO” the set zone numbers is in alarm the PGM Enter zone number “FROM” “00” – not used, operates only ZONE IN is activated) Deactivated on “AND”...
  • Page 52 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual All panic types are enabled by default. Enter the panic type: 1 – Silent panic Panic Alarm in Area – Restore 2 – Sound panic Activate on “AND” function (when all area 3 –...
  • Page 53 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual 4 – Tel. line or communication Deactivated on “OR” function (if at least one failure system trouble is present) 5 – Tamper 6 – System bus error 7 – Fire line failure 8 –...

  • Page 54: Areas

    Attention: In ECLIPSE 8 control panel is available only one area in the system - AREA 01. ECLIPSE Control Panels Series – AREA capability: Control panel Available AREAS ECLIPSE 8 ECLIPSE 16 ECLIPSE 32 Quick table for 4. AREAS Programming Menu Address Number Programming parameter...
  • Page 55 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 4000 A ACCOUNT OPERATION LENGTH TEXT MENU 6. PARTITIONS – 1. ACCOUNT LENGTH Setting the area account number digit length An account number digit length is assigned at this address. The digit length can be 4 or 6-digit. Every pressing of a random button or arrows changed alternatively the parameter.
  • Page 56 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 4003 POSTPONE OPERATION TEXT MENU 6. PARTITIONS – 4. POSTPONE TIME Automatic arming delay from Manager Enter a time from 001 to 255 minutes. The Engineer sets a time for automatic arming delay on time slot from Manager. During of a running automatic arming procedure on set time slot, (address 4xx9, where “xx”...
  • Page 57 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 4012 AREA 1 OPERATION 412 + 01 CYCLE TEXT MENU 6. PARTITIONS – 5. AREAS – 1. AREA – 03. ALARM CYCLE Setting of alarm cycle (bell time) for Area 1 Duration of the alarm cycle is set for the programmable siren type outputs associated to Area 1.
  • Page 58 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual Squawk on Sound signalization in disarming: – The sound signalization in disarming is disabled.  Disarm 2 - The sound signalization in disarming is enabled. The siren will activate twice for 1 second when disarming the Area 1. Ring Back Sound signalization for memory log record: –...
  • Page 59 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual 5 – The automatic arming on no movement in the zones is enabled. Area 1 will be automatically armed after ending the time set at ADDRESS 4002 when there is no movement in the zones associated to the Area 1.
  • Page 60 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual The following special cases are possible when a keyboard is used for sending of panic alarms: 1. In case of several panics are sent at the same time just the last one will be displayed. 2.

  • Page 61: Timeslots

    Eclipse 8/ 16/ 32 Series - Engineer Programming Manual 5. Timeslots The “TIMESLOTS” menu is available only for ECLIPSE 32 control panel. The term Time Slot is used to represent a set of functions related to time intervals. A time slot is used to automate operations fixed in time, which are periodically repeated by the security system.
  • Page 62 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 5010 OPERATION 510 + 01 START TEXT MENU 7. SCHEDULES – 1. TIMESLOTS – 1. TIMESLOT – 1. START Start time for arming on Timeslot 1 The start time of Timeslot 1 is set at this address. The start time must be less than the stop time set at address 5011.
  • Page 63 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 5013 OPERATION 513 + 01 OPTIONS TEXT MENU 7. SCHEDULES – 1. TIMESLOTS – 1. TIMESLOT – 4.OPTIONS Setting of holidays for operation on Timeslot 1 The engineer sets at this address those holidays included in the Timeslot 1 operation. When this option is enabled (1 is selected) for Timeslot 1, the system will also notes the settings at addresses 5411 –...

  • Page 64: Communication

    Please, bear in mind that the use of alarm panels over alternative telephone systems like VoIP (Voice over Internet Protocol) may not be as effective as with traditional telephone line. If you are experiencing problems with the use of a Teletek Electronics device over PSTN, please contact us for further assistance.

  • Page 65: General Parameters

    Eclipse 8/ 16/ 32 Series - Engineer Programming Manual 6.1 General Parameters At ADDRESSES 60хх are programmed common parameters of the connected to the system communication devices. ADDRESS 6000 DIGITAL OPERATION COMM TEXT MENU 8. COMMUNICATION – 1. DIGITAL COMM – 1. OPTIONS Setting of communication options The options are common for programmed telephone numbers.
  • Page 66 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 6001 ATTEMPTS OPERATION TEXT MENU 8. COMMUNICATION – 1. DIGITAL COMM – 2. ATTEMPTS Number of attempts for communication with monitoring station The Engineer sets the number of attempts to connect to the central station for telephone monitoring and the number of repetitions of voice messages at the address.
  • Page 67 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 6010 OPERATION 610 +01 NUMBER TEXT MENU 8. COMMUNICATION – 1. DIGITAL COMM – 5. PHONES – 1. PHONE – 1. PHONE NUMBER Setting of Telephone 1 for the digital communicator A Telephone 1 number is assigned for communicating with central station.
  • Page 68 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual TAMPER Message is sent in case of events: - TAMPER (from a zone; from a Tamper type zone; from a device connected to the system bus: keyboard, proxy reader, expander modules) - TAMPER Restore PANIC, AMBUSH CODE Message is sent in case of events:...

  • Page 69: Voice Dialer

    Eclipse 8/ 16/ 32 Series - Engineer Programming Manual 6.2 Voice Dialer The programming of the following addresses concerns the operation of the ECLIPSE 8/ 16/ 32 control panels with mounted voice dialer. ADDRESS 6100 OPERATION OPTIONS TEXT MENU 8. Communication – 2. Voice Dialer – 1. VD Options Programming of option for the voice dialer The options are common for all programmed telephone numbers.
  • Page 70 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 6103 OPERATION LANGUAGE TEXT MENU 8. Communication – 2. Voice Dialer – 4. VD Language Setting the language for the voice dialer messages The engineer can set the language of the voice messages transmitted from the voice dialer. Use the digit buttons to set a two-digit value for different languages.

  • Page 71: Remote Programming

    Eclipse 8/ 16/ 32 Series - Engineer Programming Manual 6.3 Remote programming The parameters for up / download programming of the integrated digital communicator are set on ADDRESSES 69хх. The remote control parameters are available only for ECLIPSE 32 control panel. ADDRESS 6900 OPERATION...
  • Page 72 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 6904 OPERATION OPTIONS TEXT MENU 8. COMMUNICATION – 1. DIGITAL COMM – 6. UDL – 5. OPTIONS Options for remote control The following options are assigned: Enabling of “Call Back” option. CALL BACK CALL BACK Disable () –...

  • Page 73: Peripheral Devices

    Max. supported devices Keyboards Proxi readers Exp.modules    ECLIPSE 8    ECLIPSE 16    ECLIPSE 32 Quick table for 8. Device Programming Menu Address Number Programming parameter ECLIPSE 8 ECLIPSE 16 ECLIPSE 32 ...
  • Page 74 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 8010 DEV 01 OPERATION 810 + 01 TEXT MENU 9. DEVICES – 01. DEVICE [MAIN] – 1. ID Identification number for Device 01. The Device 01 is always the control panel, and it is performed at the LCD display with it is unique name [MAIN] and ID number.
  • Page 75 1 proxi reader. ** Eclipse 16: Up to 5 devices can be enrolled to the system bus irrespective of their type. *** Eclipse 32: Up to 31 devices can be enrolled to the system bus irrespective of their type.
  • Page 76 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual To select all areas press button “0” – the button alternatively switches over all enabled / all disabled state. Keyboards and modules: If all areas for a device are disabled the device becomes inactive, irrespective there are any options programmed for it.
  • Page 77 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual keyboards irrespective of their type.  The option 1 can be programmed for the connected to the system bus proximity card readers.  The options must be programmed for every device separately at the respective address. ...
  • Page 78 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual ADDRESS 8024 DEV 02 OPERATION 814 + 02 COMM TEXT MENU 9. DEVICES – 02. DEVICE [NAME] – 5. COMM QUALITY Communication quality for Device 02. The engineer can check the quality of communication between the Device 02 and the control panel). This address is only for review.

  • Page 79: Appendix

    Eclipse 8/ 16/ 32 Series - Engineer Programming Manual APPENDIX APPENDIX 1. Structure of zone inputs on the ECLIPSE 32 control panel The zone numbers 09 – 16 are logical corresponding to the physical hardware terminals (connection styles 6 - 9): Physical inputs Logical inputs...
  • Page 80 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual Activated zone with AUX „GAS  Z## Gas Trbl Zone No 1 157 Trouble" attribute Restored zone with AUX „GAS  Z## Gas Trbl R Zone No 3 157 Trouble" attribute Activated zone with AUX „High ...
  • Page 81 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual Police panic alarm from keyboard  KBD## Panic R Keyboard No 3 12A restored Fire panic alarm sent from  KBD## Fire Keyboard No 1 11A keyboard Fire panic alarm from keyboard ...

  • Page 82: Appendix 3. Fire Delay Operation Algorithm (Address 2015)

    Eclipse 8/ 16/ 32 Series - Engineer Programming Manual APPENDIX 3. FIRE DELAY Operation Algorithm (ADDRESS 2015)

  • Page 83: Appendix 4. Vd/ Dtmf Operation Algorithm

    Eclipse 8/ 16/ 32 Series - Engineer Programming Manual APPENDIX 4. VD/ DTMF Operation Algorithm If during 40 seconds time interval there is no action – pressed button, the system will break up the line.

  • Page 84: Appendix 5. Text Tree-Structure Menus

    Eclipse 8/ 16/ 32 Series - Engineer Programming Manual APPENDIX 5. Text Tree-Structure Menus ECLIPSE Series The text menus are available only in operation with LCD keyboard! There are several ways for setting parameters in text menus – that depends on the Some of the text menus are not available in ECLIPSE 8/ 16 Control panel - menu: refer to the detailed descriptions in item 7!
  • Page 85 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual 2. SETTINGS 01. AMBUSH CODE Disable / Enable 02. KBD BLOCK 02. CHIME (Eclipse 8) Disable / Enable  AC LOST 03. TRBL SOUNDS NOTE!  BATT TROUBLE Use buttons:  BLOWN FUSE to DISABLE ...
  • Page 86 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual  DISARM ENABLE 3. CODES 1. USERS 01. USER 1. OPTIONS  PART.ARM ENABLE  BYPASS ENABLE 02. USER  PROGRAM ENABLE  MANAGER ENABLE 64. USER  AREA 1 2. AREAS ...
  • Page 87 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual 4. INPUTS 1. WIRING 1/2/3/4/5/6/7/8/9 2. AUTO BYPASS 0-9; 6 3. INSTANT Disable / Enable 4. PULSE COUNT 1. PULSES 0-9; 0 UNUSED NOTE!  ENTRY/EXIT Use button: FOLLOW 2. TIME OUT 000-255sec;...
  • Page 88 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual 5. OUTPUTS 1. PGM OPTION FIRE OUTPUT SERIAL LINK 2. PGMs 01. PGM 1. ATTACH 2. OPTIONS SIREN POL. INVERT (NC) DELAY 32. PGM PULSED FIRE DEACT.TIM.UNIT  AREA 1 3. AREAS AREA 2 ….
  • Page 89 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual 6. PARTITIONS 1.ACCOUNT LENGTH [ 4 / 6 ] 2. DOUBLE KNOCK [1-5 min; 3] 3. NO MOV ARM [1-255 min; 0] 4. POSTPONE TIME [0-255 min; 010] 5. AREAS 1. AREA 01.
  • Page 90 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual Note: The menus are available only for ECLIPSE 32 control panel. 7. SCHEDULES 1. TIMESLOTS 1. TIMESLOT 1. START [00:00] MESLOT 2. END [00:00] 8. TIMESLOT MESLOT 3. WEEK DAYS MONDAY TUESDAY WEDNESDAY MESLOT...
  • Page 91 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual  BLIND DIAL 8. COMMUNICATION 1. DIGITAL COMM 1. OPTIONS ENABLE DIALER  ALTERNATIVE TLM ENABLE  PSTN REP. MAIN TLM ALARM  AJAX REP. MAIN PULSE DIAL 2. ATTEMPTS [0-9; 4] NOTE! Use buttons: 3.
  • Page 92 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual 9. DEVICES 01. DEVICE [MAIN] 1. ID NOTE! Use buttons:  AREA 1 2. AREAS to DISABLE AREA 2 …. to ENABLE AREA 8 4. RESOURCES 02. DEVICE [NAME] 1. ID ...

  • Page 93: Appendix 6. Style Diagrams For Zone Connection

    Eclipse 8/ 16/ 32 Series - Engineer Programming Manual APPENDIX 6. Style Diagrams for Zone Connection (The value is checked at ADDRESS 2zz9, where “zz” is a zone number) LEGEND: “” means “lower than” value; “”means “higher than” value SINGLE ZONE CONNECTION DOUBLING ZONE CONNECTION...

  • Page 94: Appendix 7. Eclipse Series Control Panels - Main Board Connection Diagrams

    Eclipse 8/ 32 Series - Engineer Programming Manual APPENDIX 7. ECLIPSE Series Control Panels – Main board Connection Diagrams 17V/ 23VA...
  • Page 95 Eclipse 8/ 16/ 32 Series - Engineer Programming Manual...
  • Page 96 www.teletek-electronics.com Address: Bulgaria, Sofia - 1407, 14А Srebarna Str. Tel.: +359 2 9694 800, Fax: +359 2 962 52 13 e-mail: info@teletek-electronics.bg 18020737, Rev C, 03/ 2014...
