After the system console finishes its low-level system diagnostics, the SP initializes
and runs a suite of higher level diagnostics. When you access the SP using a device
connected to the SER MGT port, you see the output of the Oracle ILOM diagnostics.
By default, the SP configures the NET MGT port automatically, retrieving network
configuration settings using the Dynamic Host Configuration Protocol (DHCP) and
allowing connections using SSH.
For a more detailed discussion on configuring the system console and connecting
terminals, refer to the system administration documentation for your server.
Related Information
"Connect a Terminal or Emulator to the SER MGT Port" on page 52
■
"Power On the Server for the First Time" on page 53
■
▼ Connect a Terminal or Emulator to the
SER MGT Port
A null modem configuration is needed for DTE to DTE communications. You can use
the supplied RJ-45 crossover adapter with a standard RJ-45 cable to achieve the null
modem configuration.
1. Connect a terminal or a terminal emulator (PC or workstation) to the SER MGT

port.

2. Configure the terminal or terminal emulator with these settings:
■
■
■
■
■
3. (Optional) Connect an Ethernet cable between the server's NET MGT port and
the network to which future connections to the SP and host will be made.
Related Information
"Oracle ILOM System Console" on page 51
■
"Power On the Server for the First Time" on page 53
■
52 SPARC T4-1 Server Installation Guide • August 2013
9600 baud
8 bits
No parity
1 Stop bit
No handshake
