▼ Connect a Terminal or Emulator to the
SER MGT Port
●
Connect a terminal or a terminal emulator (PC or workstation) to the service
processor serial management port.
Configure the terminal or terminal emulator with these settings:
■
■
■
■
■
A null modem configuration is needed, meaning the transmit and receive signals
are reversed (crossed over) for DTE to DTE communications. You can use the
supplied RJ-45 crossover adapters with a standard RJ-45 cable to achieve the null
modem configuration.
Note – When you power on the server for the first time and you do not have a
terminal or terminal emulator (PC or workstation) connected to the service processor
serial management port, you will not see system messages.

▼ Prepare Power Cords

Powering on the server for the first time requires special preparation and
procedures. For example, if you have not prepared a display before connecting the
AC power cable, initial system messages could be lost.
Caution – The server goes into Standby mode and the service processor initializes
as soon as the AC power cable is connected to the power source.
●
Go to
connecting the server to AC power.
46 SPARC T4-4 Server Installation Guide • May 2014
9600 baud
8 bits
No parity
1 Stop bit
No handshake
"Power On the System for the First Time" on page 47 for instructions on
