C H A P T E R
Mounting the Server Into a 4-Post
Rack
This chapter provides instructions for installing the server in an open 4-post rack or
closed cabinet.
Note – The 19-inch 4-post hardmount rack kit is included in the standard Sun Netra
T5220 server configuration.
This chapter contains the following sections:
"4-Post Rackmounting Options" on page 22
■
"Hardmounting the Server in a 19-Inch 4-Post Rack" on page 22
■
"Mounting the Server in a Sliding Rail Mount 19-Inch 4-Post Rack" on page 26
■
"Hardmounting the Server in a 600-mm 4-Post Rack" on page 33
■
Note – References to left and right are from your viewpoint as you face either the
front or rear of the equipment.
Caution – The server is heavy. Two people are required to lift and mount the server
into a rack enclosure when following the procedures in this chapter.
21
